Motorola Symbol DS4308-HC – Barcode Scanner – Corded – 2D

Part Number: DS4308-HCBU2100AZW

Model: Symbol DS4308-HC

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Connectivity

Corded

Form Factor

Handheld

Interface Options

USB, Serial

Scanner Capability

Product Description:

DS4308-HC USB KIT with CBA-U21 -S07ZAR Shielded USB Cable

Explore all Motorola Symbol DS4308-HC Barcode Scanners

Add to Quote

Motorola DS4308-HCBU2100AZW Barcode Scanner

Overview

Full specifications (PDF)

Motorola Symbol DS4308-HC Barcode Scanner Model Overview

Barcode scanning at patient bedside is crucial in preventing medication and specimen mixups - two of the potentially deadliest errors in a hospital. but scanning bar codes in a hospital can be a challenge. There are many types of bar codes including traditional paper-based, those displayed on an electronic screen, codes printed on curved surfaces, high density codes printed on very small items and bar codes in all types of conditions - from smudged to scratched and poorly printed. Now, you can give your healthcare workers the ability to scan them all with the Ds4308-HC. This feature-rich next generation 2D imager resets the bar for scanning performance, scanning range, versatility and ease-of-use. The result? The priceless peace of mind that the right patient received the right medication and the right test results, every time. The DS4308-HC - the ideal companion for laptops on workstation-on-wheels (WoWs) and other types of carts in your hospital.

Motorola DS4308-HCBU2100AZW Barcode Scanner Overview

PROTECT PATIENT HEALTH WITH NEXT GENERATION BARCODE SCANNING

In the mission-critical world of healthcare, caregivers need to be able to accurately capture virtually any bar code, on any medium, in any condition - with first-time every time predictability. And with the DS4308-HC on your workstations-on-wheels and other carts, they can. The DS4308-HC does it all - 1D or 2D, electronic or printed on paper labels, tiny dense codes on the curved surface of a vial, codes printed on reflective surfaces like IV bags, codes under shrink wrap on doses of medication - and even smudged, scratched or poorly printed bar codes. The result? The priceless peace of mind that the right patient received the right medication and the right test results, every time.

Detailed Specs

Full specifications (PDF)

Technical Information

Connectivity Technology:

Cable

Scanning Capability:

Barcode Symbology Supported:

1D:

UPC/EAN
UPC/EAN with supplementals
Bookland EAN
ISSN
UCC Coupon Extended Code
Code 128
GS1-128
ISBT 128
Code 39
Code 39 Full ASCII
Trioptic
Code 39
Code 32
Code 93
Code 11
Matrix 2 of 5
Interleaved 2 of 5
Discrete 2 of 5
Codabar
MSI
Chinese 2 of 5
GS1 DataBar variants
Korean 3 of 5
ISBT Concat

2D:

PDF417
MicroPDF417
Composite Codes
TLC-39
Data Matrix
Maxicode
QR Code
MicroQR
Aztec
Han Xin

Postal:

Australian Post
US PLANET
Royal Mail 4 State Customer
US POSTNET
KIX Code (Dutch)
UK Postal
Japan Post
UPU 4 State Postal FICS (Post US4)
USPS 4 State Postal (Post US3)
Canadian Post (Postbar)

Image Sensor Type:

Imager

Interfaces/Ports

Host Interface:

USB

Physical Characteristics

Color:

Healthcare White

Height:

6.5"

Width:

2.6"

Length:

3.9"

Weight (Approximate):

5.71 oz

Miscellaneous

Additional Information:

USB Cable separate

Item Numbers

GTIN: 0010268164642, 0682017419107, 0783555157114, 0787739874552, 4923773173329, 4973163136397, 5712505927359

UPC: 010268164642, 682017419107, 783555157114, 787739874552

EAN: 0010268164642, 0682017419107, 0783555157114, 0787739874552, 4923773173329, 4973163136397, 5712505927359

UNSPSC: 43211701
