Motorola DS4208 – Barcode Scanner – 1D

Part Number: DS4208-HBZU000ZWR
Model: DS4208

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Form Factor
Handheld
Scanner Capability
1D
Scanner Type
Imager

Product Description:

  USB Kit, 2D Imager, High Density. Includes USB cable. Color: Black

Motorola DS4208 Barcode Scanner Model Overview

The Motorola DS4208 general purpose imager delivers the blazing speed typical of laser scanners on both 1D and 2D barcodes, accommodating 2D barcodes without sacrificing scanning quality or performance. Users never need to take time to align the barcode with the scanner or pause between scans. Since the DS4208 can scan barcodes printed on paper labels or on mobile phone displays, users can drive revenue by attracting the millions of customers who are using their cell phones to better manage their lives. Retailers can accommodate customers who download mobile coupons, mobile loyalty cards and more. Quick service restaurants can accept mobile coupons at the register. Hotels can allow guests to use electronic loyalty cards stored on their cell phones, eliminating the need to carry physical cards. And since theaters, theme parks and stadiums can scan mobile tickets as easily as a paper ticket, they can offer customers an added convenience: paperless ticketing.
Motorola DS4208-HBZU000ZWR Barcode Scanner Overview

The DS4208 delivers the blazing speed typical of laser scanners on both 1D and 2D bar codes, allowing you to accommodate 2D bar codes without sacrificing scanning quality or performance. Users never need to take time to align the bar code with the scanner or pause between scans. And since you can capture bar codes printed on paper labels or displayed on the screen of a mobile phone, retailers can accommodate customers who download mobile coupons, mobile loyalty cards and more. You get industry-leading scanning speed on every bar code; true point-and-shoot first time scanning simplicity on even damaged and poorly printed bar codes; and a durable design for all day everyday reliability - all at an affordable price.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D:

  • UPC/EAN
  • UPC/EAN with supplementals
  • Bookland EAN
  • ISSN
  • UCC Coupon Extended Code
  • Code 128
  • GS1-128
  • ISBT 128
  • Code 39
  • Code 39 Full ASCII
  • Trioptic Code 39
  • Code 32
  • Code 93
  • Code 11
  • Matrix 2 of 5
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • Codabar
  • MSI
  • Chinese 2 of 5
  • GS1 DataBar Variants
  • Korean 3 of 5
  • ISBT Concat

2D:

  • PDF417
  • MicroPDF417
  • Composite Codes
  • TL C-39
  • Data Matrix
  • Maxicode
  • QR Code
  • MicroQR
  • Aztec

Postal:

  • Australian Post
  • US PLANET
  • Royal Mail 4 State Customer
  • US POSTNET
  • KIX Code (Dutch)
  • UK Postal
  • Japan Post
  • UPU 4 State Postal FICS (Post US4)
  • USPS 4 State Postal (Post US3)
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 0.2" - 3.7"@3mil - Code 39
  • 0.1" - 4.6"@4mil - Code 39
  • 0.1" - 5.1"@5mil - Code 39
  • 0.1" - 6.4"@7.5mil - Code 39
  • 0.2" - 7.7"@10mil - Code 39
  • 0.2" - 5.4"@7.8mil - 60% UPC
  • 0.3" - 6.5"@10.4mil - 80% UPC
  • 0.7" - 7.6"@13mil - 100% UPC
  • 0.3" - 4"@5mil - Code 128
  • 0.8" - 7.2"@10mil - I2of5
  • 0.7" - 2.7"@4mil - PDF 417
  • 0.3" - 3"@5mil - PDF 417
  • 0.4" - 3.6"@6.67mil - PDF 417
  • 0.8" - 4.7"@10mil - PDF 417
  • 0.4" - 2.8"@5mil - Data Matrix
  • 0.4" - 3.9"@7.5mil - Data Matrix
  • 0.1" - 4.6"@10mil - Data Matrix
  • 0.4" - 3.9"@10mil - QR Code
Scan Pattern:
Omni-directional
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Color:
Twilight Black
Height:
6.7"
Width:
2.7"
Depth:
3.7"
Weight (Approximate):
6.10 oz
Miscellaneous
Additional Information:

USB Cable separate

Certifications & Standards:
  • UL60950-1 2nd ed
  • CSA C22.2 No. 60950-1 2nd ed
  • EN60950-1/IEC60950-1 2nd ed
  • IEC/EN60825-1:2001
  • IEC/EN62471:2006
  • FCC Part 15 Class B
  • ICES-003 Class B
  • EN55022 Class B
  • EN55024
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0853585471518, 5711045918315, 7426802312388
UPC: 853585471518
EAN: 0853585471518, 5711045918315, 7426802312388
UNSPSC: 43211701
