Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D Codes:
- UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13 plus supplementals, ISBN (Bookland), ISSN,Coupon Code)
- Code 39 (Standard, Full ASCII, Trioptic)
- Code 128 (Standard, UCC/EAN-128, ISBT-128 Concatenated)
- Code 93
- Codabar/NW7
- Code 11 (Standard, Matrix 2 of 5)
- MSI Plessey
- I 2 of 5 (Interleaved 2 of 5/ ITF, Discrete 2 of 5, IATA, Chinese 2 of 5)
- GS1 DataBar (Omnidirectional,Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked, Inverse)
- Base 32(Italian Pharmacode)
PDF417(And Variants):
- PDF417 (Standard, Macro)
- MicroPDF417(Standard, Macro)
- Composite Codes (CC-A, CC-B, CC-C)
2D Codes:
- TLC-39
- Aztec (Standard, Inverse)
- MaxiCode
- DataMatrix/ECC 200 (Standard,Inverse)
- QR Code (Standard, Inverse,Micro)
Postal Codes:
- U.S. Postnet
- U.S. Planet
- U.K. Postal
- Japan Postal
- Australian Postal
- Dutch Postal
- 4State Postal
IUID Support:
- Supports IUID parsing. The Ability To Read And Separate IUID Fields Per Application Requirements
Light Source:
Laser
Image Sensor Type:
CMOS
Depth of Field:
- 3mil - Code 39
- 2.60" - 4.50"@4mil - Code 39
- 1" - 6.30"@5mil - Code 39
- 10.10"@7.5mil - Code 39
- 1" - 20.90"@20mil - Code 39
- 0.90" - 15.10"@13mil - 100% UPC
- 2.70" - 6.10"@6.67mil - PDF417
- 0.40" - 9.30"@10mil - PDF417
- 3.30" - 14.80"@15mil - PDF417
- 4mil - Data Matrix
- 5mil - Data Matrix
- 2.10" - 5.50"@7.5mil - Data Matrix
- 1.10" - 7.10"@10mil - Data Matrix
- 4mil - QR Code
- 5mil - QR Code
- 7.5mil - QR Code
- 1.50" - 6.10"@10mil - QR Code
Scan Pattern:
Omni-directional
