Motorola DS3578-ER2F005WR Barcode Scanners


4.0

(1 reviews)

Motorola DS3578-ER - SCANNER ONLY. Long Range 2D Imager, Cordless, FIPS Security Encryption. Cradle, cables, and accessories must be purchased separately.
GET MAXIMUM PERFORMANCE, PRODUCTIVITY, SCANNING RANGE AND A RUGGED DESIGN ALL IN ONE SCANNER

With a Motorola defined maximum rugged specifications, the DS3500-ER Series of full-range scanners can handle whatever comes its way. The DS3500-ER Series allows you to scan different types of barcodes across a wide range of distances. From near contact to as far as 30 feet away. Workers can also hold the trigger down to continuously scan items. It doesn"t matter how well lit an area is, the DS3500-ER Series can read barcodes in darkness or in bright sunlight. Indoors and outdoors, you can drop it on concrete, cover it in dust or grease and continuously obtain the same reliable results.

Technical Information

  • Barcode Dimension:
    • 1D
    • 2D
  • Scan Pattern: Omni-directional
  • Connectivity Technology: Wireless
  • Scanning Distance: 30 ft
  • Light Source: Laser
  • Image Sensor: Imager
  • Barcode Symbology Supported:
    • 1D Codes:
    • UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13 plus supplementals
    • ISBN (Bookland)
    • ISSN, Coupon Code)
    • Code 39 (Standard, Full ASCII, Trioptic)
    • Code 128 (Standard, Full ASCII UCC/EAN-128, ISBT-128 Concatenated)
    • Code 93
    • Codabar/NW7
    • Code 11 (Standard, Matrix 2 of 5)
    • MSI Plessey
    • I 2 of 5 (Interleaved 2 of 5 / ITF Discrete 2 of 5, IATA, Chinese 2 of 5)
    • GS1 DataBar (Omni-directional, Truncated, Stacked, Stacked Omni-directional, Limited, Expanded, Expanded Stacked, Inverse)
    • Base 32 (Italian Pharmacode)
    • PDF417 (and Variants):
    • PDF417 (Standard, Macro)
    • microPDF417 (Standard, Macro)
    • Composite Codes (CC-A, CC-B, CC-C)
    • 2D Codes:
    • TLC-39
    • Aztec (Standard, Inverse)
    • MaxiCode
    • DataMatrix/ECC 200 (Standard, Inverse)
    • Qr Code (Standard, Inverse, Micro)
    • Postal:
    • U.S. Postnet
    • U.S. Planet
    • U.K. Postal
    • Japan Postal
    • australian Postal
    • Dutch Postal
    • 4 State Postal
    • 1D Codes:
    • UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13 plus supplementals
    • ISBN (Bookland)
    • ISSN, Coupon Code)
    • Code 39 (Standard, Full ASCII, Trioptic)
    • Code 128 (Standard, Full ASCII UCC/EAN-128, ISBT-128 Concatenated)
    • Code 93
    • Codabar/NW7
    • Code 11 (Standard, Matrix 2 of 5)
    • MSI Plessey
    • I 2 of 5 (Interleaved 2 of 5 / ITF Discrete 2 of 5, IATA, Chinese 2 of 5)
    • GS1 DataBar (Omni-directional, Truncated, Stacked, Stacked Omni-directional, Limited, Expanded, Expanded Stacked, Inverse)
    • Base 32 (Italian Pharmacode)
    • PDF417 (and Variants):
    • PDF417 (Standard, Macro)
    • microPDF417 (Standard, Macro)
    • Composite Codes (CC-A, CC-B, CC-C)
    • 2D Codes:
    • TLC-39
    • Aztec (Standard, Inverse)
    • MaxiCode
    • DataMatrix/ECC 200 (Standard, Inverse)
    • Qr Code (Standard, Inverse, Micro)
    • Postal:
    • U.S. Postnet
    • U.S. Planet
    • U.K. Postal
    • Japan Postal
    • australian Postal
    • Dutch Postal
    • 4 State Postal
  • Depth of Field:
    • 8.50" - 34"@7.50 mil - Code 39
    • 8" - 42"@10 mil - Code 39
    • 8" - 88"@20 mil - Code 39
    • 8" - 17.08 ft@55 mil - Code 39
    • 8" - 27.92 ft@100 mil - Code 39

General Information

  • Product Type: Handheld Barcode Scanner
  • Product Series: DS3500-ER
  • Brand Name: Motorola
  • Manufacturer: Motorola, Inc
  • Product Model: DS3578-ER
  • Product Name: DS3578-ER Handheld Barcode Reader

Physical Characteristics

  • Height: 7.3"
  • Width: 4.8"
  • Depth: 2.9"
  • Color:
    • Twilight Black
    • Yellow
  • Weight (Approximate): 13.79 oz

Interfaces/Ports

  • Host Interface:
    • IBM 46XX
    • Serial
    • USB
    • Keyboard Wedge

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority: RoHS

Network & Communication

  • Bluetooth: Yes

Warranty

  • Limited Warranty: 3 Year

Battery Information

  • Battery Chemistry: Lithium Ion (Li-Ion)

Full specifications (PDF)

Full specifications (PDF)

Brand Motorola
Model DS3500-ER Series
Connectivity Cordless
Connection USB
Color Yellow/Black
Communication Range less than 33 ft
Scanner Type Imager
Form Factor Handheld
Scanner Capability 2D
Scan Pattern Area
Communication Type Bluetooth
Included Cables Scanner Only - No Cable
Ruggedness Rugged


Customer Review Summary


4.0

(based on 1 reviews)

Ratings Distribution

  • 5 Stars



    (0)

  • 4 Stars



    (1)

  • 3 Stars



    (0)

  • 2 Stars



    (0)

  • 1 Stars



    (0)

100%

of respondents would recommend this to a friend.

Reviewed by 1 customers

Sort by

Displaying reviews 1-1

Back to top


4.0

Nice Scanner

By MB

from Hazleton, PA

3/13/2013

Verified Reviewer

Pros

  • Easy to setup
  • Large Distance Scanning
  • Rugged

Cons

  • Cable Difficult To Find
  • Large Manual

Best Uses

  • Inventory
  • Manufacturing

Comments about Motorola DS3578-ER DS3578-ER2F005WR:

This product is used for day-to-day raw materials and finished goods inventory. The scanners are not used lightly, and are put to the test everyday. The scanners are easy to set up, and are simple to use, but they have limitations on use, based on the pre-programmed unit.

Displaying reviews 1-1

Back to top

Recommended Accessories for Model: Motorola DS3500-ER Series Scanner

The Motorola DS3578-ER2F005WR is also known as MOT-DS3578ER2F005WR or DS3578ER2F005WR .
