Motorola AP-7522E-67030-US Access Point

Motorola AP-7522-67030-US Access Point A newer version of this item is available.
It is replaced by the Motorola AP-7522-67030-US Access Point.
Motorola AP 7522E - Express 802.11ac, Internal Antenna US
  • When connected to a compatible router or a network switch, this wireless access point lets you enjoy wireless internet connectivity throughout your home or office
  • With IEEE 802.11ac standard and up to 866.70 Mbit/s data transfer rates, this wireless access point enables efficient network performance
  • Ethernet port provides Ethernet connections for fast data transfer and large file transfers between your access point and wired network
  • Its management capability provides efficient control over setup and configuration of your network
Read More
Discontinued See Replacement
Add to Quote
Motorola AP 7522E Access Point Model Overview
Get 802.11ac speed at a low price point with the AP 7522E access point. The comprehensive feature set and 2X2 MIMO provide all your mobile users with a dependable, high-performance wireless connection. With our high-powered radios, you’ll need fewer access points, delivering maximum speed for a minimum cost. And with its sleek, understated look, the internal antenna version of the AP 7522E is at home anywhere in your environment — including customer-facing public spaces. Using WiNG Express means you can set up the network without the need for a large IT team. You can run up to 25 AP 7522E access points - without the cost of a dedicated network management controller.
Motorola AP-7522E-67030-US Access Point Overview
802.11AC WI-FI SPEED AND THROUGHPUT - ALL AT A LOW COST.

Introducing the AP 7522E from Motorola Solutions, delivering 802.11ac speeds at half the cost of many of its competitors. Now, you can support virtually any of the mobile devices on your network running today's demanding applications, with a design that fits right in to any area in your environment. The 802.11n radio ensures backward compatibility with every mobile device in use in your operation today - and 256 QAM modulation boosts the bandwidth of the 802.11n radio to 802.11ac levels. Choose internal antennas for a sleek understated look that is ideal in customer facing or carpeted office areas, or external antennas that allow you to choose the antennas you need to achieve maximum range and performance in demanding industrial areas.
Technical Information
Wireless LAN Standard:
IEEE 802.11ac
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.47 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.85 GHz
Antenna Gain:
  • 4 dBi
  • 6 dBi
Wireless Transmission Speed:
866.70 Mbit/s
Wireless Security:
WPA2
Features:
  • MIMO Technology
  • LED Indicator
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
Yes
Management & Protocols
Management:
  • WiNG Express Manager
  • Web Based Management
Physical Characteristics
Form Factor:
  • Ceiling Mountable
  • Wall Mountable
Height:
1.6"
Width:
6.5"
Depth:
7.1"
Weight (Approximate):
1.80 lb
Miscellaneous
Certifications & Standards:
Safety:
  • UL
  • cUL
  • 60950-1
  • IEC / EN60950-1
  • UL2043
Radio:
  • FCC (USA)
  • EU
  • TELEC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0749594884169, 0783555010761, 0886201165867, 4943783132598, 4943783144881
UPC: 749594884169, 783555010761, 886201165867
EAN: 0749594884169, 0783555010761, 0886201165867, 4943783132598, 4943783144881
UNSPSC: 43222631
