Motorola AP-7522-67040-WR Wireless Access Points

Part Number: AP-7522-67040-WR
Model: AP 7522
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11ac
ISM Band
Yes
UNII Band
Yes
ISM Minimum Frequency
2.41 GHz

Product Description:

  Dual Radio 802.11ac 2x2: External Antenna
Explore all Motorola AP 7522 Wireless Access Points
Add to Quote
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points
Motorola AP-7522-67040-WR Wireless Access Points Motorola AP-7522-67040-WR Wireless Access Points Motorola AP-7522-67040-WR Wireless Access Points Motorola AP-7522-67040-WR Wireless Access Points Motorola AP-7522-67040-WR Wireless Access Points Motorola AP-7522-67040-WR Wireless Access Points
Full specifications (PDF)

Motorola AP 7522 Wireless Access Points Model Overview

Get 802.11ac speed at a low price point with the AP 7522 access point. The comprehensive feature set and 2X2 MIMO provide all your mobile users with a dependable high-performance wireless connection. With our high-powered radios, you’ll need fewer access points, delivering maximum speed for a minimum cost. And with its sleek, understated look, the internal antenna version of the AP 7522 is at home anywhere in your environment — including customer-facing public spaces.
Motorola AP-7522-67040-WR Wireless Access Points Overview

UPGRADE TO 802.11AC WI-FI SPEED AND THROUGHPUT - ALL AT A LOW COST.

Your WLAN keeps your business moving, empowering your workers to achieve maximum productivity and providing your customers with the high-performance wireless services they expect inside your walls. Yet your wireless LAN is constantly pressured by the steady increase in number of users - and the bandwidth heavy and latency-sensitive voice and multi-media applications they use. Upgrading to 802.11ac could solve the problem, but cost has been an issue - until today.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11ac
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.47 GHz
UNII Minimum Frequency:
5.18 GHz
UNII Maximum Frequency:
5.85 GHz
Total Number of Antennas:
2
Number of External Antennas:
2
Antenna Connector:
RP-SMA Connector
Wireless Transmission Speed:
866.70 Mbit/s
Wireless Security:
  • WPA2
  • WPA
Features:
  • MIMO Technology
  • Quality of Service (QoS)
  • LED Indicator
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
Yes
Power Description
Input Voltage:
48 V DC
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
Height:
1.6"
Width:
6.5"
Depth:
7.1"
Weight (Approximate):
1.80 lb
Miscellaneous
Certifications & Standards:
Safety:
  • UL / cUL 60950-1
  • IEC
  • EN60950-1
  • UL2043
Radio Approvals:
  • FCC
  • EU
  • TELEC

IEEE Standards:

  • 802.11a
  • 802.11b
  • 802.11g
  • 802.11n
  • 802.11ac
  • 802.11d
  • 802.11i
  • 802.3af
  • 802.3
  • 802.1q
  • 802.1x
  • 802.1p
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Item Numbers
GTIN: 0644728010967
UPC: 644728010967
EAN: 0644728010967
UNSPSC: 43222631
