Motion Computing LR524442832343 Tablet

Part Number: LR524442832343

Model: F5te

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Processor Manufacturer

Intel

Processor Type

Core i7

64-bit Processing

Yes

Chipset Manufacturer

Intel

Product Description:

Motion F5te Rugged Tablet - 10.4" XGA - 4 GB RAM - 128 GB SSD - Windows 8 64-bit - Intel QM77 Express SoC - Intel Core i7 - 1024 x 768 - View Anywhere, AFFS+ Display - HSDPA, EVDO, EDGE - 1.3 Megapixel Front Camera - 6 Hour Maximum Battery Run Time

Explore all Motion Computing F5te Tablets

Add to Quote

Overview

Full specifications (PDF)

Motion Computing F5te Tablet Model Overview

At only 3.3 lbs. with a slip-free grip and molded handle, the Motion F5te Tablet PC is a companion tool for field workers. Powered with up to the Intel Core i7 vPro processor, the F5te offers uncompromising levels of performance and advanced remote management capabilities. Mobile workers are equipped with many integrated features to accomplish virtually any tasks their demanding environments require - indoors or outdoors.

Motion Computing LR524442832343 Tablet Overview

Industry-Leading Tablet PC Display Technologies

The Motion F5te Tablet PC is available with a dual-input display to support both capacitive ten-finger touch and high-resolution digitizer pen for increased flexibility and ease of use while gathering, accessing or transmitting data at the point of service. Navigate applications with the convenience of touch, take advantage of pen input for pinpoint accuracy or capture customer signatures in real time.

Detailed Specs

Full specifications (PDF)

Processor

Processor Manufacturer:

Intel

Processor Type:

Core i7

64-bit Processing:

Yes

Chipset

Chipset Manufacturer:

Intel

Chipset Model:

QM77 Express

Memory

Standard Memory:

4 GB

Memory Technology:

DDR3L SDRAM

Memory Standard:

DDR3L-1600/PC3-12800

Storage

Solid State Drive Capacity:

128 GB

Solid State Drive Interface:

mini-SATA

Display & Graphics

Screen Size:

10.4"

Display Screen Type:

Active Matrix TFT Color LCD

Display Screen Technology:

View Anywhere
AFFS+

Aspect Ratio:

4:3

Screen Mode:

XGA

Screen Resolution:

1024 x 768

Backlight Technology:

LED

Touchscreen:

Yes

Multi-touch Screen:

Yes

Digitizer:

Yes

Graphics Controller Manufacturer:

Intel

Graphics Controller Model:

HD 4000

Graphics Memory Capacity:

Up to 256 MB

Graphics Memory Technology:

DDR3L SDRAM

Graphics Memory Accessibility:

Shared

Network & Communication

WWAN Supported:

Yes

Gobi Supported:

Yes

Cellular Network Supported:

WCDMA
GSM

Cellular Data Connectivity Technology:

HSDPA
EVDO
EDGE

GPS:

Yes

Wireless LAN:

Yes

Wireless LAN Manufacturer:

Intel

Wireless LAN Model:

Centrino Advanced-N 6235

Wireless LAN Standard:

IEEE 802.11a/b/g/n

Bluetooth:

Yes

Bluetooth Standard:

Bluetooth 4.0

Input Devices

Keyboard Type:

Touchscreen Keyboard

Pointing Device Type:

Stylus

Built-in Devices

Front Camera/Webcam:

Yes

Front Camera/Webcam Resolution:

1.3 Megapixel

Rear Camera:

Yes

Rear Camera Resolution:

3 Megapixel

Focus Modes:

Auto-focus

Microphone:

Yes

Finger Print Reader:

Yes

Speakers:

Yes

Software

Operating System Platform:

Windows

Operating System:

Windows 8

Operating System Architecture:

64-bit

Software Included:

SnapWorks by Motion
RFID Sample Reader
Barcode Reader
Motion/Softex OmniPass Security Software
Motion Tablet Center
Know Your Motion Tablet
Pen and Touch Enabled BIOS Setup

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Energy:

40 Wh

Maximum Battery Run Time:

6 Hour

Power Description

Input Voltage:

110 V AC
220 V AC

Maximum Power Supply Wattage:

65 W

Physical Characteristics

Rugged:

Yes

Form Factor:

Slate

Height:

Width:

10"

Depth:

10"

Weight (Approximate):

3.30 lb

Miscellaneous

Package Contents:

F5te Tablet PC
Lithium Ion Battery
AC Adapter
Stylus

Certifications & Standards:

MIL-STD-810G
IP54

Standards:

ACPI 3.0b compliant

Safety:

AS/NZS 60950-1
FCC/ANSI C63.41
UL, CUL, CE (IEC/EN60950-1 A11/2004)
ETSI EN 62311
LVD (73/23/EEC)
EU Directive 2002/95/EC
EU Directive 2002/96/EC
EU Directive 2006/66/EC and its amendments
California Proposition 65
Technical Instructions for Safe Transport of Dangerous Goods by Air (ICAO Doc #9284)
Emergency Response Guidance for Aircraft incidents involving Dangerous Goods (ICAO Doc #9481)

Regulatory:

AS/NZS 3548:1995 Class B
AS/NZS 4268
AS/ACIF S042.1 (WCDMA/HSDPA)
AS/ACIF S042.3 (WCDMA/HSDPA)
AS/ACIF S042.1 (GSM/EDGE)
AS/ACIF S042.3 (GSM/EDGE)
CAN/CSA ICES-003 Class B
CAN/CSA RSS-210 Issue 5
CAN/CSA RSS-310 Issue 2
CAN/CSA RSS-132 (1xRTT/EVDO-0/EVDO-A)
CAN/CSA RSS-133 (1xRTT/EVDO-0/EVDO-A)
CENELEC EN 60601-1-2
CENELEC EN 55022 Class B (CISPR22)
CENELEC EN 55024 (CISPR24)
CENELEC EN 61000-3-2
CENELEC EN 61000-3-3
ETSI EN 301-893
ETSI EN 300-328
ETSI EN 300-440
ETSI EN 301-489-1
ETSI EN 301-489-3
ETSI EN 301-489-7
ETSI EN 301-489-17
ETSI EN 301-489-24
ETSI EN 300-330
ETSI EN 301-511
ETSI EN 301-908
FCC Part 15 Subpart B Class B
FCC Part 15 Subpart C (2.4 GHz)
FCC Part 15 Subpart E (5 GHz)
FCC Part 22 H (1xRTT/EVDO-0/EVDO-A)
FCC Part 24 E (1xRTT/EVD0-0/EVDO-A)
R&TTE (89/336/EEC) & R&TTE (99/5/EC)

Features:

Gorilla Glass

Security Features:

TCG Trusted Platform Module (TPM) 1.2
Barcode Reader 1D/2D

Environmentally Friendly:

Yes

Environmental Certification:

WEEE
RoHS

Warranty

Limited Warranty:

3 Year

Item Numbers

UNSPSC: 43211509
