Motion Computing LM537532834343 Tablet

Part Number: LM537532834343

Model: F5t

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Processor Manufacturer

Intel

Processor Type

Core i7

Processor Generation

3rd Gen

Processor Model

i7-3767U

Product Description:

Motion F5 Rugged Tablet - 10.4" XGA - 8 GB RAM - 256 GB SSD - Windows 7 64-bit - Intel QM77 Express SoC - Intel Core i7 3rd Gen i7-3767U 2 GHz - 1024 x 768 - AFFS+, View Anywhere Display - 1.3 Megapixel Front Camera - 6 Hour Maximum Battery Run Time

Explore all Motion Computing F5t Tablets

Add to Quote

Overview

Full specifications (PDF)

Motion Computing F5t Tablet Model Overview

At only 3.3 lbs the Motion-Computing F5t makes it easy to take technology into the field for streamlined processes and increased productivity. Available with up to the 3rd generation Intel Core i7 vPro processor, the F5t offers uncompromising levels of increased power, security and manageability. With extended battery life of up to 6 hours (1), a hot-swap battery feature, superior performance and advanced remote management capabilities, mobile workers are equipped with a robust computing tool for accomplishing virtually any task. Lightweight, rugged and mobile, the F5t enhances documentation and collaboration with integrated digital cameras, barcode scanner or RFID reader. Keep workers connected with integrated Bluetooth, WiFi and Gobi connectivity. The F5t is meticulously designed, thoroughly developed and purposely built for field productivity.

Motion Computing LM537532834343 Tablet Overview

Uncompromising Tablet PC Performance. Exceptional Field Capabilities.

At only 3.3 lbs the Motion® F5t makes it easy to take technology into the field for streamlined processes and increased productivity. Available with up to the 3rd generation Intel® Core™ i7 vPro™ processor, the F5t offers uncompromising levels of increased power, security and manageability. With extended battery life of up to 6 hours, a hot-swap battery feature, superior performance and advanced remote management capabilities, mobile workers are equipped with a robust computing tool for accomplishing virtually any task.

Detailed Specs

Full specifications (PDF)

Processor

Processor Manufacturer:

Intel

Processor Type:

Core i7

Processor Generation:

3rd Gen

Processor Model:

i7-3767U

Processor Speed:

2 GHz

Chipset

Chipset Manufacturer:

Intel

Chipset Model:

QM77 Express

Memory

Standard Memory:

8 GB

Maximum Memory Supported:

8 GB

Memory Technology:

DDR3 SDRAM

Memory Standard:

DDR3-1600/PC3-12800

Storage

Solid State Drive Capacity:

256 GB

Solid State Drive Interface:

mini-SATA/300

Optical Drive Type:

Display & Graphics

Screen Size:

10.4"

Display Screen Type:

Active Matrix TFT Color LCD

Display Screen Technology:

AFFS+
View Anywhere

Aspect Ratio:

4:3

Screen Mode:

XGA

Screen Resolution:

1024 x 768

Backlight Technology:

LED

Touchscreen:

Yes

Multi-touch Screen:

Yes

Digitizer:

Yes

Graphics Controller Manufacturer:

Intel

Graphics Controller Model:

HD 4000

Graphics Memory Capacity:

Up to 256 MB

Graphics Memory Technology:

DDR3 SDRAM

Graphics Memory Accessibility:

Shared

Network & Communication

WWAN Supported:

Yes

Gobi Supported:

Yes

GPS:

Yes

Wireless LAN:

Yes

Wireless LAN Manufacturer:

Intel

Wireless LAN Model:

Centrino Advanced-N 6235

Wireless LAN Standard:

IEEE 802.11a/b/g/n

Bluetooth:

Yes

Bluetooth Standard:

Bluetooth 4.0

Input Devices

Keyboard Type:

Touchscreen Keyboard

Pointing Device Type:

Stylus

Built-in Devices

Front Camera/Webcam:

Yes

Front Camera/Webcam Resolution:

1.3 Megapixel

Rear Camera:

Yes

Rear Camera Resolution:

3 Megapixel

Focus Modes:

Auto-focus

Microphone:

Yes

Speakers:

Yes

Software

Operating System Platform:

Windows

Operating System:

Windows 7

Operating System Architecture:

64-bit

Software Included:

Motion Dashboard control panel
Windows Journal
Sticky Notes
Pen and Touch enabled BIOS setup
Intel Mobile Clinical Assistant
Adobe Reader
Mobile Broadband Connection Manager
Adobe Flash Player

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Energy:

40 Wh

Maximum Battery Run Time:

6 Hour

Power Description

Input Voltage:

110 V AC
220 V AC

Maximum Power Supply Wattage:

65 W

Physical Characteristics

Rugged:

Yes

Form Factor:

Slate

Height:

Width:

10.1"

Depth:

10.1"

Weight (Approximate):

3.30 lb

Miscellaneous

Package Contents:

F5t Tablet PC
Lithium Ion Battery
AC Adapter
Stylus

Certifications & Standards:

ACPI 3.0b Compliant
Section 508 Compliant
AS/NZS 3548:1995 Class B
AS/NZS 4268
AS/ACIF S042.1 (WCDMA/HSDPA)
AS/ACIF S042.3 (WCDMA/HSDPA)
AS/ACIF S042.1 (GSM/EDGE)
AS/ACIF S042.3 (GSM/EDGE)
CAN/CSA ICES-003 Class B
CAN/CSA RSS-210 Issue 5
CAN/CSA RSS-310 Issue 2
CAN/CSA RSS-132 (1xRTT/EVDO-0/EVDO-A)
CAN/CSA RSS-133 (1xRTT/EVDO-0/EVDO-A)
CENELEC EN 60601-1-2
CENELEC EN 55022 Class B (CISPR22)
CENELEC EN 55024 (CISPR24)
CENELEC EN 61000-3-2
CENELEC EN 61000-3-3
ETSI EN 301-893
ETSI EN 300-328
ETSI EN 300-440
ETSI EN 301-489-1
ETSI EN 301-489-3
ETSI EN 301-489-7
ETSI EN 301-489-17
ETSI EN 301-489-24
ETSI EN 300-330
ETSI EN 301-511
ETSI EN 301-908
FCC Part 15 Subpart B Class B
FCC Part 15 Subpart C (2.4 GHz)
FCC Part 15 Subpart E (5 GHz)
FCC Part 22 H (1xRTT/EVDO-0/EVDO-A)
FCC Part 24 E (1xRTT/EVD0-0/EVDO-A)
R&TTE (89/336/EEC) & R&TTE (99/5/EC)
AS/NZS 60950-1
FCC/ANSI C63.41
UL, CUL, CE (IEC/EN60950-1 A11/2004)
ETSI EN 62311
LVD (73/23/EEC)
EU Directive 2002/95/EC
EU Directive 2002/96/EC
EU Directive 2006/66/EC
California Proposition 65
Technical Instructions for Safe Transport of Dangerous Goods by Air (ICAO Doc #9284)
Emergency Response Guidance for Aircraft incidents involving Dangerous Goods (ICAO Doc #9481)
