Motion Computing HH2A2A3A2A2A2A Tablet

Name: Motion Computing HH2A2A3A2A2A2A Tablet
Brand: Motion Computing
SKU: 113284

Part Number: HH2A2A3A2A2A2A

Model: J3500

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Processor Manufacturer

Intel

Processor Type

Core i5

Processor Generation

1st Gen

Processor Model

i5-520UM

Product Description:

Motion J3500 HH2A2A3A2A2A2A Rugged Tablet - 12.1" WXGA - 2 GB RAM - Windows 7 - Intel QM57 Express SoC - Intel Core i5 1st Gen i5-520UM Dual-core (2 Core) 1.06 GHz - 1280 x 800 - 3.50 Hour Maximum Battery Run Time

Explore all Motion Computing J3500 Tablets

Add to Quote

Overview

Full specifications (PDF)

Motion Computing J3500 Tablet Model Overview

The Motion-Computing J3500 is a rugged and powerful slate tablet computer for field professionals across vertical markets that need a robust device for often harsh mobile work environments. Now with the power of Intel Core i7 and i5 vPro processors, the J3500 offers new levels of power, security and manageability. It's rugged, and it's packed with integrated features that enable real-time, on-site productivity.

Motion Computing HH2A2A3A2A2A2A Tablet Overview

The Motion J3500 Tablet PC features a rugged design for mobile professionals across industries that require full PC functionality in a highly mobile device. The J3500 is available with a variety of the latest available technologies that improve productivity when computing while on the move, whether indoors or out.

Detailed Specs

Full specifications (PDF)

Processor

Processor Manufacturer:

Intel

Processor Type:

Core i5

Processor Generation:

1st Gen

Processor Model:

i5-520UM

Processor Speed:

1.06 GHz

Processor Core:

Dual-core (2 Core)

Cache:

3 MB

Direct Media Interface:

2.50 GT/s

64-bit Processing:

Yes

Hyper-Threading:

Yes

Chipset

Chipset Manufacturer:

Intel

Chipset Model:

QM57 Express

Memory

Standard Memory:

2 GB

Maximum Memory Supported:

4 GB

Memory Technology:

DDR3 SDRAM

Memory Standard:

DDR3-800/PC3-6400

Number of Total Memory Slots:

Storage

Hard Drive Capacity:

160 GB

Hard Drive Interface:

Serial ATA/300

Hard Drive RPM:

5400

Display & Graphics

Screen Size:

12.1"

Display Screen Type:

Active Matrix TFT Color LCD

Aspect Ratio:

16:9

Screen Mode:

WXGA

Screen Resolution:

1280 x 800

Backlight Technology:

LED

Touchscreen:

Yes

Multi-touch Screen:

Yes

Digitizer:

Yes

Graphics Controller Manufacturer:

Intel

Graphics Controller Model:

HD Graphics

Graphics Memory Capacity:

Up to 256 MB

Graphics Memory Technology:

DDR3 SDRAM

Graphics Memory Accessibility:

Shared

Network & Communication

Wireless LAN:

Yes

Wireless LAN Manufacturer:

Intel

Wireless LAN Model:

Centrino Ultimate-N 6300

Wireless LAN Standard:

IEEE 802.11a/b/g/n

Ethernet Technology:

Gigabit Ethernet

I/O Expansions

Expansion Slot Type:

ExpressCard/34

Interfaces/Ports

Total Number of USB Ports:

Number of USB 2.0 Ports:

VGA:

Yes

Network (RJ-45):

Yes

Audio Line In:

Yes

Audio Line Out:

Yes

Input Devices

Pointing Device Type:

Stylus

Built-in Devices

Microphone:

Yes

Finger Print Reader:

Yes

Speakers:

Yes

Software

Operating System Platform:

Windows

Operating System:

Windows 7

Software Included:

Motion Dashboard Control Panel
Motion QuickNav
Motion/Softex OmniPass Security software
Windows Journal
Sticky Notes
Infineon Security Platform Tools
Pen enabled BIOS Setup
Adobe Acrobat Reader

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Energy:

30 Wh

Maximum Battery Run Time:

3.50 Hour

Power Description

Input Voltage:

110 V AC
220 V AC

Maximum Power Supply Wattage:

65 W

Physical Characteristics

Rugged:

Yes

Form Factor:

Slate

Height:

Width:

12.7"

Depth:

9.1"

Weight (Approximate):

3.60 lb

Miscellaneous

Package Contents:

J3500 Tablet PC
Lithium Ion Battery
AC Adapter
Stylus

Certifications & Standards:

IP54 tested
MIL-STD-810G
Section 508 compliant
ACPI 3.0b compliant

Safety:

AS/NZS 3260:1997
AS/NZS 60950-1
FCC/ANSI C63.41
UL, CUL, CE (IEC/EN60950-1 A11/2004)
CAN/CSA RSS-102
FCC OET65 Supplement C
ETSI EN 50392
LVD (73/23/EEC)
EU Directive 2002/95/EC
EU Directive 2002/96/EC
EU Directive 2006/66/EC and its amendments
California Proposition 65
Technical Instructions for Safe Transport of Dangerous Goods by Air (ICAO Doc #9284)
Emergency Response Guidance for Aircraft incidents involving Dangerous Goods (ICAO Doc #9481)

Regulatory:

AS/NZS 3548:1995 Class B
AS/NZS 4771
AS/NZS 4268
CAN/CSA ICES-003 Class B
CAN/CSA RSS-210 Issue 5
CENELEC EN 55022 Class B (CISPR22)
CENELEC EN 55024 (CISPR24)
CENELEC EN 61000-3-2
CENELEC EN 61000-3-3
ETSI EN 301-893
ETSI EN 300-328
ETSI EN 301-489-1
ETSI EN 301-489-3
ETSI EN 301-489-7
ETSI EN 301-489-17
ETSI EN 301-489-24
ETSI EN 300-330
ETSI EN 301-511
ETSI EN 301-908
FCC Part 15 Subpart B Class B
FCC Part 15 Subpart C (2.4Ghz)
FCC Part 15 Subpart E (5Ghz)
R&TTE (89/336/EEC) & R&TTE (99/5/EC)

Energy Star:

Yes

Environmentally Friendly:

Yes

Environmental Certification:

ENERGY STAR

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 43211509
