Mist PD-9001GR/AT/AC Accessory

The Mist PD-9001GR/AT/AC Accessory has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Mist - Power Over Ethernet Injector: MicrosemiÆs PD-9001GR is a single port, high-power solution for Mist Access Points. Generating up to 30W, the PD-9001GR complies with IEEE 802.3at PoE+ standard and is backward compatible with IEEE802.3af

Need a different version? See all Mist Parts Accessories

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Mist PD-9001GR/AT/AC Accessory
Mist PD-9001GR/AT/AC Accessory Mist PD-9001GR/AT/AC Accessory
Mist PD-9001GR/AT/AC Accessory
Mist PD-9001GR/AT/AC Accessory
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Maximum Output Voltage:
55 V DC
Maximum Input Current:
800 mA
Minimum Frequency:
50 Hz
Maximum Frequency:
60 Hz
Maximum Output Power:
30 W
Interfaces/Ports
Input Ports:
1 x 10/100/1000Base-T
Output Ports:
1 x 10/100/1000Base-T
Physical Characteristics
Height:
1.3"
Width:
2.2"
Length:
5.5"
Weight (Approximate):
7.04 oz
Miscellaneous
Compatibility:
  • Access Points
  • Pan-Tiltzoom (PTZ) Cameras
  • Video-Phones
  • Network Devices
Certifications & Standards:
  • CE
  • FCC Part 15, Class B
  • EN 55022 Class B (Emissions)
  • EN 55024 (Immunity)
  • VCCI
  • UL/cUL Per IEC 60950-1
  • IEEE802.3af
  • IEEE802.3at
  • GS
    • Environmentally Friendly:
    Yes
    Country of Origin:
    China
    Warranty
    Limited Warranty:
    1 Year
    Item Numbers
    GTIN: 0818245045201
    UPC: 818245045201
    EAN: 0818245045201
    UNSPSC: 39121004
