Metrologic MS3780 Fusion – Barcode Scanner – 1D

Part Number: MK3780-61B41/EAS
Model: MS3780 Fusion
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Capability
1D
Scanner Type
Laser

Product Description:

  RS-232 kit. Omni-Directional Laser, Integrated EAS. Includes RS-232 cable, power supply, and stand. Color: Dark Gray

Honeywell MS3780 Fusion Barcode Scanner Model Overview

Experience unparalleled efficiency in your retail operations with the Fusion™ M 3780 Omnidirectional Laser Scanner by Honeywell. This compact, hand-held scanner combines advanced omnidirectional and single-line scanning capabilities, making it a versatile addition to medium-volume retail environments such as specialty stores and pharmacies. With features like an automatic in-stand operation and a user-friendly design, the Fusion 3780 enhances checkout speeds while reducing operator fatigue, helping you streamline your workflow like never before.


Key Features:

  • Omnidirectional Scan Pattern: Aggressive scanning from any angle for increased throughput.
  • Single-Line Scan Mode: Switch to a targeted single line for precise scanning with a button press.
  • Automatic In-Stand Detection: Enables hands-free operation, significantly reducing operator fatigue.
  • Integrated IR Sensor: Powers up the scanner only when a barcode is detected, conserving energy.
  • Optional RF EAS Integration: Simultaneously deactivates RF tags while scanning barcodes for heightened efficiency.

Specifications:

  • Mechanical Dimensions: 189 mm x 65 mm x 73 mm (7.4" x 2.6" x 2.9")
  • Weight: 195 g (6.9 oz)
  • Electrical:
    • Input Voltage: 5 VDC ± 0.25 V
    • Operating Power: 1.4 W (275 mA @ 5 V)
    • Standby Power: 1.0 W (200 mA @ 5 V)
    • Host System Interfaces: USB, RS232, Keyboard Wedge, IBM 46xx (RS485), OCIA
  • Environmental:
    • Operating Temperature: -20°C to 40°C (-4°F to 104°F)
    • Storage Temperature: -40°C to 60°C (-40°F to 140°F)
    • Humidity: 5% to 95% relative humidity, non-condensing
    • Drop: Designed to withstand multiple 1.5 m (5') drops
    • Environmental Sealing: Sealed to resist airborne particulate contaminants
    • Light Levels: 4842 Lux
  • Scan Performance:
    • Scan Pattern: Omnidirectional with 5 fields of 4 parallel lines; single line activated by button
    • Scan Speed: 1,333 scan lines per second (omnidirectional); 67 scan lines per second (single line)
    • Print Contrast: 35% minimum reflectance difference
    • Pitch, Skew: 60°, 60°
    • Decode Capability: Reads standard 1D and GS1 DataBar symbologies
  • Warranty: 3-year factory warranty
Metrologic MK3780-61B41/EAS Barcode Scanner Overview

Metrologic Fusion combines omni directional and single-line laser bar code scanning into a lightweight, ergonomic hand-held form factor. The 20-line scan pattern provides superior scanning over existing single-line scanners making Fusion ideal for medium-volume retailers including specialty stores, pharmacies, liquor stores, and convenience stores. An adjustable stand with three locking positions provides flexibility for the user to position the scanner for individual comfort and optimal performance. Stabilized with a weighted metal base, the stand may also be hard-mounted to counters or walls.

Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • All Standard 1D Symbologies
  • RSS-Expanded
  • RSS-14
  • RSS-Limited
Light Source:
Laser
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1.7" - 4.5"@5.2mil
  • 1" - 7.5"@7.5mil
  • 1" - 9.5"@10.4mil
  • 1" - 11"@13mil
  • 1" - 12"@19.5mil
Scan Pattern:
  • Single Line
  • Omni-directional
Cable Type Included:
Serial
Stand Included:
Yes
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Power Supply Included:
Yes
Physical Characteristics
Color:
Gray
Height:
2.9"
Width:
2.6"
Depth:
7.4"
Weight (Approximate):
6.90 oz
Miscellaneous
Package Contents:
  • Fusion MS3780 Bar Code Reader
  • 110V Power Supply
  • Stand
  • RS-232 Cable
Additional Information:

Supported Interfaces:

  • Serial
  • Keyboard Wedge
  • IBM 468X/469X
  • USB
  • OCIA
  • Item Numbers
    UNSPSC: 43211701
