Honeywell MS3580 QuantumT – Barcode Scanner – Corded – 1D – Scanner with Cable and Stand

Part Number: MK3580-31A38
3-year Premium Plus ($103.48)
3-year Premium ($48.78)
No Support
$401.93
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Presentation
Interface Options
USB
Scanner Capability
1D

Product Description:

  Corded Scanner, Metrologic MS3580 QuantumT, 1D Laser/Omni-directional, General Purpose, USB, Presentation, 9.2' Straight USB Cable/Weighted Base, Black
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
  • All Standard 1D Symbologies
  • RSS-Expanded
  • RSS-14
  • RSS-14 Limited
Light Source:
Laser
Scan Rate:
1650 scan/s
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1.5" - 4"@5.2mil
  • 0.8" - 7.3"@7.5mil
  • 0.8" - 9.3"@10.4mil
  • 0.8" - 10"@13mil
  • 0.8" - 11.8"@26mil
Scan Pattern:
  • Omni-directional
  • Single Line
Scanning Distance:
11.73"
Cable Type Included:
USB
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Maximum Ambient Light:
4842 lux
Drop Specification:
Designed to withstand 1.5 m (5´) drops
Minimum Print Contrast:
35%
Interfaces/Ports
Host Interface:
USB
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
Desktop
Rugged:
Yes
Color Family:
Black
Product Color:
Black
Height:
4.3"
Width:
2.7"
Length:
2.6"
Weight (Approximate):
6 oz
Miscellaneous
Package Contents:
  • QuantumT MS3580 Bar Code Reader
  • Rubber Boot mounted on plastic base
  • Cable
  • Manuals
Additional Information:

Supported Interfaces:

  • Serial
  • Light Pen Emulation
  • Keyboard Wedge
  • IBM 468X/469X
  • USB
  • OCIA
  • Laser Emulation

USB Cable separate

Application/Usage:
Retail
Certifications & Standards:

Laser Class:

  • Class 1; IEC60825-1:1993/A1:1997+A2:2001
  • Class 1; EN60825-1:1994/A11:1996+A2:2001

EMC:

  • FCC, ICES-003 & EN55022 Class A
Item Numbers
GTIN: 0024606615727, 0091419502087, 0641676217608, 0783555036563, 0804904096196, 0808112937173, 0809395314774, 0880959552641, 5052461756243, 7898409751257
UPC: 024606615727, 091419502087, 641676217608, 783555036563, 804904096196, 808112937173, 809395314774, 880959552641
EAN: 0024606615727, 0091419502087, 0641676217608, 0783555036563, 0804904096196, 0808112937173, 0809395314774, 0880959552641, 5052461756243, 7898409751257
UNSPSC: 43211701
