Meru AP832I Data Networking

The Meru AP832I Data Networking has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Meru - Meru AP832i IEEE 802.11ac 1.27 Gbit/s Wireless Access Point - 2 x Network (RJ-45) - Ethernet, Fast Ethernet, Gigabit Ethernet - Wall Mountable, Ceiling Mountable, Desktop
  • Create a reliable wireless business network with this wireless access point that features a high-speed data transfer rate
  • This wireless access point uses IEEE 802.11ac technology with steadfast speed of up to 1.27 Gbit/s for optimal wireless signals
  • Featuring Fast Ethernet port to speed up the transfer rate up to 100Mb/sec to connect your wired network
Read More

Need a different version? See all Meru Parts Accessories

Discontinued Need Assistance?
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Meru AP832I Data Networking
Meru AP832I Data Networking
Meru AP832I Data Networking
Meru AP832I Data Networking Meru AP832I Data Networking Meru AP832I Data Networking
Meru Parts Accessory Model Overview
Products and parts from Meru.
Meru AP832I Data Networking Overview
High-performance wireless connectivity for high-density environments

The AP832 is the industry's first 802.11ac access point capable of supporting two concurrent 5 GHz 3x3:3ss radios, designed for high-density deployments in large offices, schools, universities, hospitals, hotels, and large retail stores. The AP832 supports an aggregate 2.6 Gbps data rate for the most demanding business applications like video and voice.

The AP832 access point allows administrators to prioritize applications to improve the user experience with Meru's unique Context Aware Layers technology. For schools, this means Learning Management System applications can be assigned to one dedicated channel layer, while online classroom video feeds can be dedicated to another channel layer. For healthcare, lifecritical applications such as patient monitoring can be dynamically assigned to one channel layer, doctor and nursing applications can be assigned to a second layer, and patient applications can be placed on a third channel layer.
Technical Information
Wireless LAN Standard:
IEEE 802.11ac
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.40 GHz
ISM Maximum Frequency:
2.48 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.83 GHz
Total Number of Antennas:
6
Antenna Gain:
  • 3 dBi
  • 4 dBi
Antenna Type:
Omnidirectional Antenna
Wireless Transmission Speed:
1.27 Gbit/s
Wireless Security:
  • WEP
  • WPA-PSK
  • WPA-TKIP
  • WPA2-AES
  • 802.11i
  • 802.1X
  • EAP-TLS
  • EAPTTLS
  • PEAP
  • LEAP
  • EAP-FAST
  • EAP-SIM
  • EAP-AKA
  • EAP-MD5
Features:
Quality of Service (QoS)
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
2
Network (RJ-11):
No
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
Yes
Powerline:
No
Management Port:
Yes
Management & Protocols
Management:
  • SNMP
  • E(z)RF Network Manager
Power Description
Input Voltage:
12 V DC
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
  • Desktop
Height:
7.1"
Width:
7.1"
Depth:
2.7"
Weight (Approximate):
2.30 lb
Miscellaneous
Package Contents:
  • Dual-Radio, Three-Stream 802.11ac Wireless Access Point
  • T-Bar & Wall-Mount Combo Adapter
  • T-Bar Adapter
  • Flat-Surface Wall-Mount Bracket
Certifications & Standards:
  • FCC
  • CE Mark
  • TELEC
  • Industry Canada
IEEE Standards:
  • 802.11ac
  • 802.11a
  • 802.11b
  • 802.11g
  • 802.11n
  • 802.11i
  • 802.1af
  • 802.1X
  • 802.3af
Environmentally Friendly:
Yes
Environmental Certification:
EU RoHS
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0855716005098
UPC: 855716005098
EAN: 0855716005098
UNSPSC: 43222631
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Meru AP832I Data Networking is also known as MER-AP832I
