Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna

Part Number: ACC-ANT-O6ABGN-0607-PT
Model: Antennas
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Directivity
Directional
Frequency Band Type
UHFSHF
Operating Frequency Range
2.4 GHz to 2.5 GHz5.1 GHz to 5.85 GHz
Antenna Gain
7 dBi

Product Description:

  Meru ACC-ANT-O6ABGN-0607-PT Antenna - 7 dBiPatch - DirectionalDirectional
Explore all Meru Antennas Accessories
Add to Quote
Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna
Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna
Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna

Meru Antennas Accessory Model Overview

Optional, additional Antennas for Meru Access Points.
Meru ACC-ANT-O6ABGN-0607-PT Wireless Antenna Overview

The ACC-ANT-O6ABGN-0607-PT is a dual band 3-patch antenna for use in 802.11n MIMO applications. Housed in a low-profile Radome, the antenna can be mounted to a wall or mast, indoors or outdoors. Each of the three MIMO antenna elements is connected to the Meru AP300 Access Point via a low loss, plenum rated, coax pigtail.

The radiation patterns are uniform and symmetrical, providing high levels signal density into defined coverage zones. This antenna will greatly enhance the performance of 802.11n systems. The dual band frequency coverage means that a single type of antenna can be deployed with any MIMO radio in the 2.4-2.5 GHz or 5.1-5.850 GHz bands.

Technical Information
Directivity:
Directional
Frequency Band Type:
  • UHF
  • SHF
Operating Frequency Range:
  • 2.4 GHz to 2.5 GHz
  • 5.1 GHz to 5.85 GHz
Antenna Gain:
7 dBi
Polarization:
Vertical
Interfaces/Ports
Number of Connectors:
1
Connector Type:
RP-SMA
Physical Characteristics
Height:
17.50"
Width:
6.10"
Depth:
1"
Form Factor:
Patch
Miscellaneous
Application/Usage:
Wireless Data Network
Additional Information:

3ft Cable

Compatibility:

Meru AP300 Access Point

Item Numbers
UNSPSC: 43221706
