Meru ACC-ANT-ABGN-23 Wireless Antenna

Part Number: ACC-ANT-ABGN-23
Model: Antennas
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Directivity
Omni-directional
Frequency Band Type
UHFSHF
Operating Frequency Range
2.4 GHz to 2.5 GHz4.9 GHz to 5.9 GHz
Antenna Gain
4 dBi

Product Description:

  Meru ACC-ANT-ABGN-23 External MIMO Antenna - 4 dBi - 3 x RP-SMA
Explore all Meru Antennas Accessories
Add to Quote
Meru ACC-ANT-ABGN-23 Wireless Antenna
Meru ACC-ANT-ABGN-23 Wireless Antenna

Meru Antennas Accessory Model Overview

Optional, additional Antennas for Meru Access Points.
Meru ACC-ANT-ABGN-23 Wireless Antenna Overview

The ACC-ANT-ABGN-23 is a dual band 3-element omni-directional antenna for use in 802.11n MIMO applications. Housed in a compact, low-profile PVC/Acrylic Radome, the antenna can be mounted to a variety of drop ceiling grids using the integrated spring clips. It can also be mounted to a flush surface via the four mounting holes. Each of the three MIMO antenna elements is connected to the Meru AP300. Access Point via a low loss, plenum rated, coax pigtail.

Technical Information
Directivity:
Omni-directional
Frequency Band Type:
  • UHF
  • SHF
Operating Frequency Range:
  • 2.4 GHz to 2.5 GHz
  • 4.9 GHz to 5.9 GHz
Antenna Gain:
4 dBi
Polarization:
Linear Vertical
Interfaces/Ports
Number of Connectors:
3
Connector Type:
RP-SMA
Physical Characteristics
Height:
0.87"
Width:
3.67"
Weight (Approximate):
13.76 oz
Miscellaneous
Application/Usage:
Wireless Data Network
Additional Information:
  • Maximum VSWR: 2.0:1
  • Radome: PVC/Acrylic
Item Numbers
UNSPSC: 43221706
