LG 55VH7E-A Digital Signage Display

LG VH7E Series - 55VH7E-A Digital Signage Display - 55" LCD - 1920 x 1080 - LED - 700 Nit - 1080p - HDMI - USB - DVI - SerialEthernet
  • Brightness(Typ.) : 700 cd/m²
  • Bezel : 0.9 mm (Even)
  • Depth : 86.5 mm
  • Interface : HDMI(2)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
Read More
$4,536.00

Full specifications (PDF)

Artistic Immersion, Overwhelming Captivation
The VH7E series was designed with an extremely narrow 0.9 mm bezel that becomes even more powerful with a state-of-the-art signage platform. Designed with an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. With the built-in SoC and webOS smart signage platform, the VH7E series can execute several tasks at once while providing smooth content playback without the need for a media player.
LG 55VH7E-A Overview

Artistic Immersion, Overwhelming Captivation

The impressive immersion generated by the extremely narrow 0.9 mm bezel becomes even more powerful with a state-of-the-art smart signage platform. Beyond the self-playing feature, the VH7E series is capable of multitasking that raises brand awareness, drives traffic to your store, and engages customers in brand storytelling.

Achieving Incredible Immersion

Seamless Large Screens with Extreme-Narrow Bezel

The borderless design, with its 0.9 mm even bezel and 1.8 mm BtB (Bezel to Bezel), verified by Nemko, minimizes bezel interference and delivers immersive and seamless content on assembled video wall screens.

Achieving Incredible Immersion


Image Gap Reduction

The VH7E series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience.

Vivid and Dynamic Picture Quality

Higher Viewing Angle

Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VH7E series is high enough to display vivid colors throughout the screen with no distortion.

Vivid and Dynamic Picture Quality

Wider Viewing Angle

It is well known that LG IPS panel technology provides better control of liquid crystals, which in turn allows the screen to be viewed at virtually any angle. Thereby, the VH7E series captivates the attention of more viewers with lifelike colors, regardless of their viewing position.

Powerful Smart Signage Platform

High Performance and Great Scalability

Thanks to its built-in SoC and webOS smart signage platform, the VH7E series can execute several tasks at once while providing smooth content playback without the need for a media player. As webOS supports HTML5 as a web-based platform and offers SDK(Soft Development Kit), it is even easier for SIs to build and optimize.

Powerful Smart Signage Platform

Flexible Content Creation

Several different videos can be played simultaneously via web apps, and various animation effects, such as scaling or rotating, are added to content using CSS(Cascading Style Sheets) transition effects. Real-time streaming is also available, providing the flexibility to organize and diversify content free from capacity limits.

User-Friendly Smart Signage UX

Intuitive Menu Structure

The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trialand-error when exploring desired functions and managing displays.

User-Friendly Smart Signage UX

Dedicated GUI for Portrait Orientation

The conventional GUI(Graphic User Interface) was designed based on landscape-oriented consumer TV usage, so OSD(On Screen Display)wasn't well-suited for screens in portrait mode. The OSD of the VH7E series, however, consists of a long range menu, creating a comfortable and efficient business environment.

User Convenience

Easy Color Adjustment

Depending on the content, the color temperature of the display can be easily adjusted in increments of 100K using a remote control.

Full specifications (PDF)

Technical Information
Video Wall Compatible:
Yes
Bezel Width (Bottom):
35.4 mil
Bezel Width (Top):
35.4 mil
Bezel Width (Left):
35.4 mil
Bezel Width (Right):
35.4 mil
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Backlight Technology:
LED
Video
Scan Format:
1080p
Dynamic Contrast Ratio:
500,000:1
Brightness:
700 Nit
Network & Communication
Ethernet:
Yes
Interfaces/Ports
USB:
Yes
DVI:
Yes
HDMI:
Yes
Serial:
Yes
Number of USB 2.0 Ports:
1
Number of HDMI Inputs:
2
Number of DisplayPorts:
1
Number of DVI Ports:
1
Software
Operating System:
WebOS
Power Description
Input Voltage:
120 V AC
Physical Characteristics
Height:
26.9"
Width:
47.7"
Depth:
3.4"
Weight (Approximate):
41.01 lb
Miscellaneous
Package Contents:
  • 55VH7E-A Digital Signage Display
  • Remote Controller, Power Cord
  • RS232C Cable
  • LAN Cable
  • DP Cable
  • IR Receiver
  • Guide Bracket
  • Screws
  • Manual
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
ENERGY STAR 7.0
Item Numbers
GTIN: 0719192624726
UPC: 719192624726
EAN: 0719192624726
UNSPSC: 43211902


The LG 55VH7E-A is also known as LGE-55VH7EA or 55VH7EA .
