Lenovo 7X10A0EGNA Server

Part Number: 7X10A0EGNA
Model: Parts
$3,946.12
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
2
Number of Processors Installed
1
Processor Type
Xeon Silver
Processor Generation
2nd Gen

Product Description:

  Servers, Lenovo ThinkSystem, ST550, 4U Tower Server, 1 x Intel Xeon Silver 4208 2.10 GHz, 32 GB RAM, 12GBps SAS, Serial ATA/600 Controller, Intel C624 Chip, 2 Processor Support, 768 GB RAM Support, Matrox G200 Up to 16 MB Graphic Card, Gigabit Ethernet, 8 x LFF Bay(s), Hot Swappable Bays, 1 x 750 W

Lenovo Parts Products Model Overview

Products and parts from Lenovo.
Lenovo 7X10A0EGNA Server Overview
The Lenovo ThinkSystem ST550 2-socket 4U rack-mountable tower server provides outstanding performance and industry-leading reliability. Now available with second-generation Intel Xeon Scalable processors, the ST550 is ideal for small-to-medium businesses, distributed enterprises, retail, educational institutions and branch offices.
Processor
Number of Processors Supported:
2
Number of Processors Installed:
1
Processor Type:
Xeon Silver
Processor Generation:
2nd Gen
Processor Model:
4208
Processor Core:
Octa-core (8 Core)
Processor Speed:
2.10 GHz
Cache:
11 MB
Chipset
Chipset Manufacturer:
Intel
Chipset Model:
C624
Memory
Standard Memory:
32 GB
Maximum Memory Supported:
768 GB
Memory Technology:
TruDDR4
Memory Clock Speed:
2.93 GHz
Error Checking:
ECC
Total Number of Memory Slots:
12
Number of Occupied Memory Slots:
1
Signal Processing:
Registered (Buffered)
Storage
Total Hard Drive Capacity:
No
Controllers
Controller Type:
  • 12Gb/s SAS
  • Serial ATA/600
Controller Model:
5350-8i
RAID Supported:
Yes
I/O Expansions
Number of Total Expansion Bays:
8
Number of 3.5" Bays:
8
Number of LFF Bays:
8
Hot Swappable Bays:
Yes
Total Number of Expansion Slots:
6
PCI Express x8 (Gen 3.x) Slots:
2
PCI Express x16 (Gen 3.x) Slots:
4
PCI Express Details:
Slot 1: PCIe 3.0 x8 (25W), Slot 2: PCIe 3.0 x16 (75W), Slot 3: PCIe 3.0 x16 (75W), Slot 4: PCIe 3.0 x16 (x8 wired) (25W), Slot 5: PCIe 3.0 x16 (75W), Slot 6: PCIe 3.0 x8 (x4 wired) (25W)
Display & Graphics
Graphics Controller Model:
G200
Graphics Memory Capacity:
16 MB
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports:
9
Number of USB 2.0 Ports:
5
Number of USB 3.0 Ports:
4
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
3
VGA:
Yes
Number of VGA Ports:
1
Remote Management:
Yes
Remote Management Controller:
XClarity Controller (XCC) Enterprise
Operating System
Operating System Supported:
  • Windows Server 2016
  • Windows Server 2019
  • Windows Server 2022
  • Red Hat Enterprise Linux 7.6
  • Red Hat Enterprise Linux 7.7
  • Red Hat Enterprise Linux 7.8
  • Red Hat Enterprise Linux 7.9
  • Red Hat Enterprise Linux 8
  • Red Hat Enterprise Linux 8.1
  • Red Hat Enterprise Linux 8.2
  • Red Hat Enterprise Linux 8.3
  • Red Hat Enterprise Linux 8.4
  • Red Hat Enterprise Linux 8.5
  • Red Hat Enterprise Linux 8.6
  • Red Hat Enterprise Linux 9.0
  • SUSE Linux Enterprise Server 12 SP4
  • SUSE Linux Enterprise Server 12 SP5
  • SuSE Linux Enterprise Server 15
  • SUSE Linux Enterprise Server 15 SP1
  • SUSE Linux Enterprise Server 15 SP2
  • SUSE Linux Enterprise Server 15 SP3
  • SUSE Linux Enterprise Server 15 SP4
Operating System:
No
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Supported:
2
Number of Power Supplies Installed:
1
Plug/Connector Type:
C13
Maximum Power Supply Wattage:
750 W
Hot Swappable Power Supply:
Yes
Physical Characteristics
Form Factor:
Tower
Rack Height:
4U
Height:
17.2"
Width:
6.9"
Depth:
26"
Weight (Approximate):
79.37 lb
Miscellaneous
Package Contents:
  • ThinkSystem ST550 7X10A0EGNA Server
  • Power Cord
Security Features:
  • Power-on Password
  • Administrator's Password
  • Trusted Platform Module (TPM)
  • Supporting TPM 1.2 or TPM 2.0
  • Kensington Cable Slot
  • Lockable Side Cover
Energy Star:
Yes
Environmentally Friendly:
Yes
Energy Efficiency Certification:
ENERGY STAR 2.1
Energy Efficiency Compliance:
Energy-related Products Directive Lot 3 (ErP Lot 3)
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211501

Frequently Asked Questions

The Lenovo ThinkSystem ST550 features 1 x Intel Xeon Silver 4208 processor running at 2.10 GHz with support for up to 2 processors total. This configuration delivers enterprise-grade performance suitable for server workloads in warehouse and logistics environments. We offer this model ready for deployment in your data center infrastructure.

The Lenovo ThinkSystem ST550 supports up to 768 GB of RAM, with the unit shipping standard with 32 GB. This substantial memory capacity enables efficient handling of large datasets and concurrent operations typical in warehouse management and logistics applications. Contact us today to discuss memory upgrade options available from our inventory.

The ST550 includes 8 x LFF (Large Form Factor) hot-swappable drive bays with support for SAS and Serial ATA/600 storage controllers via a 12 Gbps interface. The hot-swappable design allows for seamless drive replacement without downtime, critical for continuous warehouse operations. Visit barcodesinc.com to explore compatible storage solutions we offer for this platform.

Yes, the ST550 is designed for enterprise workloads including virtualization, database management, and resource-intensive logistics software. With dual-processor support, up to 768 GB RAM, and the Intel C624 chipset, it provides the performance foundation needed for complex warehouse management systems. We can help you configure the optimal setup for your specific operational requirements.

This server includes Gigabit Ethernet connectivity for network operations and a Matrox G200 graphics card with up to 16 MB of memory for display management. The networking capability supports standard 802.3ab Gigabit Ethernet compliance for reliable data transmission in your warehouse infrastructure. Contact us today for information about additional networking adapters we offer for this model.

The Lenovo ThinkSystem ST550 is a 4U tower server with a 1 x 750 W power supply, providing efficient power delivery for enterprise operations. The tower form factor makes it suitable for standard server rack installations in warehouse data centers. We offer this model with full technical support and can assist with power management planning for your facility.
