Lenovo 21FA002TUS Workstation PC

Part Number: 21FA002TUS
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Release Month
May
Release Year
2023
AI-powered
Yes
Processor Manufacturer
Intel

Product Description:

  Workstation PCs, Lenovo ThinkPad Edge, 16" Mobile Workstation, WQXGA, 2560 x 1600, Intel Core i7 13th Gen i7-13700HX Hexadeca-core (16 Core), 32 GB Total RAM, 1 TB SSD, Villi Black, Storm Gray, Intel WM790 Chip, Windows 11 Pro, NVIDIA RTX 2000 Ada, In-plane Switching (IPS) Technology, English Keyboard, Front Camera/Webcam, IEEE 802.11ax Wireless LAN Standard

Lenovo ThinkPad P16 Gen 2 Laptop Model Overview

The Lenovo ThinkPad P16 Gen 2 is a premium 16-inch performance laptop designed for high-performance creative and technical work on the move. High-performance Intel processing pairs with professional graphics options, fast SSD storage and a detailed 16-inch display. Specifications and availability vary by Lenovo machine type and selected configuration.
Key features:
  • Professional Laptop Performance: Combines high-performance processing with professional graphics options for demanding mobile workflows.
  • Professional Display Options: 16:10 display choices support detailed technical, analytical and creative work.
  • ISV-Certified Configurations: Selected configurations are certified for professional engineering and creative applications.
  • ThinkPad Durability: Commercial construction and ThinkPad testing support frequent travel and field use.
  • Business Connectivity: Modern wired, wireless and display connections support desks, docks and mobile work.

Specifications:
  • Processor: 13th-generation Intel Core i5, i7 or i9 HX-series, with select 14th-generation options
  • Memory: Up to 192GB DDR5 non-ECC or 128GB DDR5 ECC memory
  • Storage: Multiple PCIe NVMe SSD options
  • Graphics / Display: 16-inch 16:10 display options with professional NVIDIA RTX graphics
  • Design / Power: 94Wh battery with Rapid Charge
  • Best-Fit Industries: advanced CAD, engineering simulation, 3D rendering, animation and data science
Lenovo 21FA002TUS Workstation PC Overview

OUR MOST POWERFUL MOBILE WORKSTATIONS

Fusing the portability of ThinkPad with the power of a workstation, P Series laptops feature ISV-certified applications, lightning-fast graphics & processing, and more cutting-edge technology to handle your compute-intensive needs - in a surprisingly thin, light package.

Technical Information
Release Month:
May
Release Year:
2023
AI-powered:
Yes
Processor
Processor Manufacturer:
Intel
Processor Type:
Core i7
Processor Generation:
13th Gen
Processor Model:
i7-13700HX
Processor Core:
Hexadeca-core (16 Core)
Processor Threads:
24
Maximum Turbo Speed:
5 GHz
vPro Technology:
No
Chipset
Chipset Manufacturer:
Intel
Chipset Model:
WM790
Memory
Total Installed System Memory:
32 GB
Maximum Supported System Memory:
192 GB
System Memory Technology:
DDR5 SDRAM
System Memory Speed:
5600 MHz
System Memory Form Factor:
SoDIMM
Installed Slot Memory:
32 GB
Installed Slot Memory Configuration:
2 x 16GB
Total Number of Memory Slots:
4.0
Number of Occupied Memory Slots:
2.0
Memory Card Supported:
SD
Storage
Drive Type:
SSD
Total Solid State Drive Capacity:
1 TB
SSD Form Factor:
M.2
Display & Graphics
Screen Size:
16"
Display Screen Technology:
  • In-plane Switching (IPS) Technology
  • Eyesafe
Standard Refresh Rate:
165 Hz
Screen Mode:
WQXGA
Screen Resolution:
2560 x 1600
Brightness:
500 Nit
Color Gamut:
100% sRGB
Touchscreen:
No
Graphics Controller Manufacturer:
NVIDIA
Graphics Controller Model:
RTX 2000 Ada
Graphics Memory Capacity:
8 GB
Graphics Memory Technology:
GDDR6
Graphics Memory Accessibility:
Dedicated
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11ax
SIM Size Supported:
Nano
Bluetooth:
Yes
WWAN Supported:
Yes
Near Field Communication:
No
Built-in Devices
Camera Privacy Shutter:
Yes
Front Camera/Webcam:
Yes
Infrared Camera:
Yes
Finger Print Reader:
Yes
Interfaces/Ports
HDMI:
Yes
Total Number of USB Ports:
3
Number of USB 3.2 Gen 1 Type-A Ports:
2
Number of USB 3.2 Gen 2 Type-C Ports:
1
Number of Thunderbolt 4 Ports:
2
Operating System
Operating System Platform:
Windows
Operating System:
Windows 11 Pro
Operating System Language:
English
Input Devices
Keyboard Backlight:
Yes
Keyboard Localization:
English
Power Description
Maximum Power Supply Wattage:
170 W
USB Power Delivery Support:
Yes
Physical Characteristics
Color Family:
Dual Color
Product Color:
  • Villi Black
  • Storm Gray
Cover Material:
  • Glass Fiber
  • Aluminum
  • Polyphenylene Sulfide (PPS)
Height:
1.19"
Width:
14.3"
Depth:
10.5"
Weight (Approximate):
6.50 lb
Miscellaneous
Package Contents:
  • ThinkPad P16 Gen 2 21FA002TUS Mobile Workstation
  • AC Adapter
  • Charger Included:
    Yes
    Features:
    • Anti-glare Screen
    • Tamper Detection
    • Low Blue Light
    Windows Hello Compatible:
    Yes
    Energy Star:
    Yes
    TCO Certified:
    Yes
    Environmentally Friendly:
    Yes
    Environmental Certification:
    • TCO Certified 9.0
    • Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
    • ENERGY STAR 8.0
    Energy Efficiency Certification:
    ENERGY STAR 8.0
    Environmental Compliance:
    Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty:
    3 Year
    Additional Warranty Information:
  • 3-year, Courier or Carry-in
  • 3Y Sealed Battery Add On, 3Y Premier Support Upgrade from 3Y Courier/Carry-in
  • Item Numbers
    GTIN: 0197529886618
    UPC: 197529886618
    EAN: 0197529886618
    UNSPSC: 43211503

    Frequently Asked Questions

    The Lenovo 21FA002TUS is a 16-inch mobile workstation featuring an Intel Core i7-13700HX hexadeca-core processor, 32 GB of RAM, and 1 TB SSD storage. It includes an NVIDIA RTX 2000 Ada graphics card, WQXGA display (2560 x 1600), and runs Windows 11 Pro, making it suitable for demanding professional applications in design, engineering, and content creation workflows.

    While the Lenovo 21FA002TUS is primarily designed as a high-performance mobile workstation for professional design and engineering work, its robust specifications and portability make it adaptable for logistics management roles requiring advanced software. For warehouse-specific mobile computing needs, we offer a range of purpose-built mobile computers and tablets optimized for AIDC operations—contact us today to discuss the best solution for your warehouse environment.

    The Lenovo 21FA002TUS features a 16-inch WQXGA display with In-plane Switching (IPS) technology at 2560 x 1600 resolution. IPS technology provides superior color accuracy and wide viewing angles, making it ideal for professional work requiring precise color reproduction and detailed visual clarity.

    The Lenovo 21FA002TUS includes IEEE 802.11ax wireless LAN standard (Wi-Fi 6), providing fast and reliable wireless connectivity for modern enterprise networks. It also features a front-facing webcam for video conferencing and collaboration, supporting remote work and communication needs.

    The Lenovo 21FA002TUS ships with Windows 11 Pro, which includes enhanced security features, device encryption, and enterprise management capabilities suitable for IT procurement environments. The Intel WM790 chipset provides additional security and stability for professional workstation operations.

    We offer the Lenovo 21FA002TUS and other Lenovo workstation solutions through our comprehensive AIDC product catalog. Visit barcodesinc.com to browse our full selection of workstations, mobile computers, and accessories, or contact us today for pricing, availability, and technical consultation tailored to your organization's needs.
