Lenovo 10291BU Products

Part Number: 10291BU
Model: ThinkServer TD230
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
2
Number of Processors Installed
1
Processor Type
Xeon
Processor Model
E5645

Product Description:

  1 x Xeon E5645 (2.40 GHz) Processor, 6 CPU Cores, 4 x 3.5" HS SAS/SATA Hard Drive Bays, 1 x 4GB 1333MHz rDIMM RAM, 1 x 625W Fixed Power Supply, DVD RW Optical Drive
Explore all Lenovo ThinkServer TD230 Products
Add to Quote
Lenovo 10291BU Products
Lenovo 10291BU Products
Lenovo 10291BU Products
Lenovo 10291BU Products
Lenovo 10291BU Products Lenovo 10291BU Products Lenovo 10291BU Products Lenovo 10291BU Products
Full specifications (PDF)

Lenovo ThinkServer TD230 Products Model Overview

The ThinkServer TD230 is an affordable dual-socket tower server that delivers great value. It is ideal for branch / remote offices and growing enterprises that are looking for a powerful server, flexible enough to run most line-of-business applications. Powered by the latest Intel Xeon platform, the ThinkServer TD230 supports up to 12 processor cores and offers up to 60% faster performance than legacy servers. However, all that power does not mean you will pay more in energy costs. The ThinkServer TD230 features power supplies that are over 90% efficient and the servers are ENERGY STAR 1.0 compliant which can save up to hundreds of dollars per year in energy costs. The ThinkServer TD230 offers a great balance in up front value, reduced total cost of ownership and provides for future expansion. With dual-sockets, up to 32GB memory and up to 10TB of storage, the ThinkServer TD230 is ready to grow with you.
Lenovo 10291BU Products Overview

Ready to innovate? Done. Because the next generation of Lenovo ThinkServers is here. They're more powerful, easier, and greener than any ThinkServers yet. And with more performance per watt, they deliver lower total cost of ownership and a higher return on your investment. That's the ThinkServer difference-big power for small budgets.

Full specifications (PDF)
Processor
Number of Processors Supported:
2
Number of Processors Installed:
1
Processor Type:
Xeon
Processor Model:
E5645
Processor Core:
Hexa-core (6 Core)
Processor Speed:
2.40 GHz
Cache:
12 MB
QuickPath Interconnect:
5.86 GT/s
64-bit Processing:
Yes
Hyper-Threading:
Yes
Chipset
Chipset Manufacturer:
Intel
Chipset Model:
5500
Memory
Standard Memory:
4 GB
Maximum Memory Supported:
32 GB
Memory Technology:
DDR3 SDRAM
Memory Standard:
DDR3-1333/PC3-10600
Total Number of Memory Slots:
8
Storage
Total Hard Drive Capacity:
No
Optical Drive Type:
DVD-Writer
Optical Media Supported:
DVD-RAM/±R/±RW
Dual-Layer Media Supported:
Yes
Controllers
Controller Type:
  • Serial Attached SCSI (SAS)
  • Serial ATA
RAID Supported:
Yes
RAID Levels:
0, 1, 5, 10
I/O Expansions
Number of Total Expansion Bays:
6
Number of External 5.25" Bays:
2
Number of 3.5" Bays:
4
Total Number of Expansion Slots:
5
Number of PCI Slots:
1
Number of PCI Express x4 Slots:
1
Number of PCI Express x8 Slots:
3
Display & Graphics
Graphics Memory Capacity:
32 MB
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports:
7
Number of USB 2.0 Ports:
7
Network (RJ-45):
Yes
VGA:
Yes
Remote Management:
Yes
Operating System
Operating System:
No
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Number of Power Supplies Installed:
1
Maximum Power Supply Wattage:
625 W
Physical Characteristics
Color Family:
Black
Product Color:
Business Black
Form Factor:
Tower
Rack Height:
5U
Height:
18.5"
Width:
8.3"
Depth:
20.1"
Weight (Approximate):
57.60 lb
Miscellaneous
Environmentally Friendly:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0645743362659
UPC: 645743362659
EAN: 0645743362659
UNSPSC: 43211501
