Lantronix EMG851000S Wireless Router
Request a Bulk Pricing Quote
Chat with a Product Expert
Lantronix Parts Server Model Overview
Parts and products from Lantronix.
Lantronix EMG851000S Wireless Router Overview
Secure access to IT equipment with RS-232 and USB console ports Access devices via Telnet/SSH or a Web browser-based console client without any proprietary software. Leverage the command line interface of most IT equipment for reconfiguring, rebooting and reloading firmware from a single point of contact. Connect in-band with dual Gigabit Ethernet or Wi-Fi and through out-of-band connections including dial-up or cellular connectivity. Various configurations all you to deploy what you need at each location, up to 8 ports: RJ-45 serial or serial USB.
Power Description
Input Voltage Range:
9V DC to 30V DC
Physical Characteristics
Weight (Approximate):
3 lb
Miscellaneous
Additional Information:
Security and Authentication: Enterprise-grade security Secure Sockets Layer(TLS v1, v1.1,v1.2) Packet filtering (firewall) Per port user permissions Configurable user/group rights Remote authentication: LDAP/AD, RADIUS, Kerberos, TACACS+, NIS Local username/password NIST-certified implementation of AES (Advanced Encryption Standards) as specified by FIPS-197 FIPS 140-2 compliant cryptography (Certificate #1878) Serial Device Port Access:
Software programmable reversible pinouts on device ports Telnet/SSH to EMG command line interface Telnet/SSH/RAW-TCP direct to an IP address HTML5 support for Java-free web terminal SSH access to console ports Multiple Telnet/SSH sessions Simultaneous user access to the same console port Customizable multi-level user menus RJ45 and/or USB device ports Automatic port-initiated connections to a network host or outbound SSH connections to neighboring equipment Enable CLI terminal logins from any device port SD card and USB Data Capture and Notification:
Port buffering-256 KB per port Port logging to local files, syslog, USB thumb drive, SD card, and NFS share System, audit and port logging Event notification via email, SNMP or Syslog entry Character string recognition Management:
Quick setup and configuration web interface (TLS) CLI setup script CLI (Telnet, SSH, WebTerminal or direct console port access) SNMP (MIB II) -v1, v2, v3 compatible, custom MIBs RPM (remote power management) feature to control and monitor industry leading PDU & UPS devices Active user list display, port monitoring and timeout Diagnostics and port status counters Performance monitoring utility Packet generation utility Network trace utility Digital I/O inputs and special integration with Sensorsoft environmental sensors Local subnet search for other Lantronix console manager solutions Maximum 15 users per device port Additional Protocols Supported:
DHCP and BOOTP for dynamic IP address assignment NTP for time synchronization FTP, TFTP, SFTP, SCP client for file transfers DNS IP address name resolution SSH, TLS, SSL, Telnet and TCP for connections in/out of every device port, UDP, PPP with PAP/CHAP, NFS and CIFS for data storage StrongSwan IPsec VPN client RIP and RIPv2 IPv6 Addressing supported Interfaces:
RS232 Serial 4-Port Front Panel: USB Host port, microSD/SDHC slot, RS-232 console Back Panel: Dual Gb Ethernet or Dual Gb fiber SFP ports Back Panel: Two (2) customer replaceable connectivity module slots for LTE/4G cellular, Wi-Fi, or dial up modem out-of-band options Memory: 1 GB Internal NAND Flash 1 GB Internal DRAM Internal Storage: 128GB Flash (optional) External Storage: microSD slot for up to 128 GB Flash
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
Thailand
Warranty
Item Numbers
GTIN:
0783384239616
UPC:
783384239616
EAN:
0783384239616
UNSPSC:
43223100
