Standard Memory:
250 GB
Lantronix 83X-72S-554-NAA Data Networking
Part Number:
83X-72S-554-NAA
Model:
Parts
Lantronix Parts Server Model Overview
Parts and products from Lantronix.
Lantronix 83X-72S-554-NAA Data Networking Overview
- The Lantronix LM-Series are console servers that also serve as a platform for network management automation.
- Managed devices are monitored over the console port at a default of every 30 seconds, providing data for rules-based decision-making and device remediation.
- Modular design to deploy what you need at each location, up to 104 ports in one rack unit: RJ-45 serial or Ethernet. Modem options include cellular, POTS line, fiber, even satellite links for out-of-band access anywhere on the planet.
- Virtual ports and port forwarding let you use the out-of-band platform as a resilient toolbox for secure access to all your network infrastructure.
- FIPS 142-2 Level 2 certification available.
Memory
Media & Performance
Media Type Supported:
Twisted Pair
I/O Expansions
Total Number of Expansion Slots:
3
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Standard:
10/100/1000Base-T
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Serial Port:
Yes
Management Port:
Yes
Number of Network (RJ-45) Ports:
3
Number of USB Ports:
2
Number of Serial Ports:
72
Environmental Conditions
Minimum Operating Temperature:
32°F (0°C)
Maximum Operating Temperature:
113°F (45°C)
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Input Voltage Range:
100 - 240 VAC
Power Consumption:
60 W
Input Current:
1.30 A
Frequency:
- 50 Hz
- 60 Hz
Physical Characteristics
Form Factor:
Rack-mountable
Height:
1.7"
Width:
17.5"
Depth:
10.4"
Weight (Approximate):
8.20 lb
Miscellaneous
Package Contents:
72-Port LM83X 2 x Power Cords 2 x Rack Mount Ears 4 x Mounting Screws 1 x USB-A to USB-C cable 1 x Connection Instruction Sheet 1 x Warranty Booklet 1.5M Cable LCD Module LMS
Additional Information:
72 Serial Ports, 3 Ethernet Ports,1.5M Cable + LCD ,includes LMS
Environmentally Friendly:
Yes
Environmental Compliance:
- China Restriction of Hazardous Substances (China RoHS)
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin:
United States
TAA Compliant:
Yes
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN:
0783384256651
UPC:
783384256651
EAN:
0783384256651
UNSPSC:
43222625
