Juniper SRX-MP-1VDSL2-R Data Networking

Juniper Networks - RoHS compliant 1 port VDSL2, MPIM form factor supported on SRX300 and SRX550

Interface Module offers enhanced dependability with maximum productivity
With VDSL2 technology, get up to 100Mbps download and upload speed over service provider link
Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
Mini-PIM form factor for your convenience and simplicity of usage
Interface Module with data networking application/usage for maximum dependability and convenience

Need a different version? See all Juniper Parts Accessories

$463.92

Recommended TrueSupport Coverage (/mo.)

Add to Quote

Overview

Juniper Parts Accessory Model Overview

Products and parts from Juniper.

Juniper SRX-MP-1VDSL2-R Data Networking Overview

Very-high-bit-rate digital subscriber line (VDSL) technology is part of the xDSL family of modem technologies, which provide faster data transmission over a single flat untwisted or twisted pair of copper wires. The 1-Port VDSL2 Annex A Mini-PIM carries the Ethernet backplane. When the Mini-PIM is plugged into the chassis, the Mini-PIM connects to one of the ports of the baseboard switch. The 1-Port VDSL2 Annex A Mini-PIM on the SRX Series Services Gateway provides ADSL backward compatibility.

Detailed Specs

Technical Information

Application/Usage:

Data Networking

Interfaces/Ports

Total Number of Ports:

Connector Type:

RJ-11

Interfaces/Ports Details:

1 x RJ-11 VDSL2 Network

Media & Performance

Media Type Supported:

Twisted Pair

Network Technology:

VDSL2

Physical Characteristics

Form Factor:

Mini-PIM

Height:

3.8"

Width:

5.9"

Depth:

0.8"

Weight (Approximate):

0.25 lb

Miscellaneous

Environmentally Friendly:

Yes

Environmental Certification:

REACH
RoHS
WEEE

Warranty

Limited Warranty:

1 Year

Item Numbers

GTIN: 0832938073494

UPC: 832938073494

EAN: 0832938073494

UNSPSC: 43222628
