Juniper Networks MX104-AC Data Routers

Part Number: MX104-AC
Model: MX104
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
USB
Yes
Powerline
No
Management Port
Yes
Token Ring Port
No

Product Description:

  MX104 Chassis with 4 MIC Slots, 4X10GE XFP Built-in Ports (License required for activation), AC Power Supply, Fan Tray w/Filter, Packet Forwarding Engine & Routing Engine
Explore all Juniper MX104 Wireless Routers
Add to Quote
Juniper Networks MX104-AC Data Routers
Juniper Networks MX104-AC Data Routers
Juniper Networks MX104-AC Data Routers Juniper Networks MX104-AC Data Routers
Full specifications (PDF)

Juniper MX104 Wireless Router Model Overview

The SDN-ready MX104 3D Universal Edge Router is a modular, highly redundant, and full-featured MX Series platform built for space- and power-constrained service provider and enterprise facilities. The MX104 offers 80 Gbps of capacity, a redundant control plane for high availability, as well as four fixed 10GbE ports and four Modular Interface Card (MIC) slots for flexible network connectivity and virtualized network services. Optimized for mobile applications and central office deployments, the MX104 is also ETSI 300 compliant, environmentally hardened for deployment in outside cabinets and remote terminals, and supports advanced timing features.
Juniper Networks MX104-AC Data Routers Overview

The MX104 Universal Edge Router is a modular, full featured MX Series platform for space and power constrained service provider and enterprise facilities. It is optimized for the aggregation of enterprise, mobile, business, and residential access services, and can also deliver edge services for metro providers.

The MX104 simplifies metro and enterprise architectures by eliminating unnecessary layers, dramatically reducing CapEx and OpEx without compromising performance or capabilities.

Full specifications (PDF)
Interfaces/Ports
USB:
Yes
Powerline:
No
Management Port:
Yes
Token Ring Port:
No
Serial V.35 Interface:
No
I/O Expansions
Number of Total Expansion Slots:
8
Expansion Slot Type:
  • Modular Interface Card (MIC)
  • SFP+
Network & Communication
Ethernet Technology:
10 Gigabit Ethernet
Management & Protocols
Security Features:
NAT
Power Description
PoE (RJ-45) Port:
No
Input Voltage:
  • 110 V AC
  • 220 V AC
Redundant Power Supply Supported:
Yes
Power Source:
Power Supply
Physical Characteristics
Form Factor:
  • Rack-mountable
  • Desktop
Height:
6.1"
Width:
17.5"
Depth:
9.5"
Weight (Approximate):
32 lb
Miscellaneous
Package Contents:
  • MX104 3D Universal Edge Router
  • 1 x AC Power Supply,
  • Fan Tray
  • Filter
Certifications & Standards:
Safety:
  • CAN/CSA-C22.2 No. 60950-1
  • UL 60950-1
  • EN 60950-1
  • IEC 60950-1
  • EN 60825-1 +A1+A2
EMC:
  • EN 300 386 V1.3.3
  • EMI (Emission)
  • FCC Part 15 Class A
  • EN 55022 Class A
  • VCCI Class A
  • BSMI CNS 13438
  • NCC C6357
Immunity:
  • EN 55024 +A1+A2 (1998)
  • EN-61000-3-2 (2006)
  • EN-61000-3-3 +A1 +A2 +A3 (1995)
  • EN-61000-4-2 +A1 +A2 (1995)
  • EN-61000-4-3 +A1+A2 (2002)
  • EN-61000-4-4 (2004)
  • EN-61000-4-5 (2006)
  • EN-61000-4-6 (2007)
  • EN-61000-4-11 (2004)
NEBS:
  • SR-3580 (2007)
  • GR-63-Core (2006)
  • GR-1089-Core (2006)
  • GR-3108-CORE
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0190801050400
UPC: 190801050400
EAN: 0190801050400
UNSPSC: 43201602
