Juniper Networks EX4300-48P Ethernet Switch

Part Number: EX4300-48P
Model: EX4300
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$8,078.49

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
48
Token Ring Port
No
LRE Port
No
Bypass
No

Product Description:

  EX4300, 48-Port 10/100/1000BaseT PoE-plus + 1100W AC PS
Explore all Juniper EX4300 Network Switches
Add to Quote
Juniper Networks EX4300-48P Ethernet Switch
Juniper Networks EX4300-48P Ethernet Switch
Juniper Networks EX4300-48P Ethernet Switch Juniper Networks EX4300-48P Ethernet Switch
Full specifications (PDF)

Juniper EX4300 Network Switch Model Overview

The Juniper Networks EX4300 line of Ethernet switches delivers the performance and scale required for both campus and data center Gigabit Ethernet (GbE) access switch deployments. Combined with Juniper’s market leading Virtual Chassis technology, the EX4300 scales up to 10 members, delivering the high availability and plug-and-play scale that businesses demand. Combining compact, pay-as-you-grow economics and low power and cooling with the performance, availability, and port densities of chassis-based platforms, the EX4300 with Virtual Chassis technology enables businesses to deploy with speed and agility to increase revenue and improve productivity.
Juniper Networks EX4300-48P Ethernet Switch Overview
The Juniper Networks® EX4300 line of Ethernet switches with Virtual Chassis technology combines the carrier-class reliability of modular systems with the economics and flexibility of stackable platforms, delivering a high-performance, scalable solution for data center, campus, and branch office environments.

Offering a full suite of Layer 2 and Layer 3 switching capabilities, the EX4300 satisfies a variety of high-performance applications, including branch, and data center access deployments as well as Gigabit Ethernet (GbE) access deployments. A single 24- port or 48-port switch can be deployed initially. As requirements grow, Juniper Networks Virtual Chassis technology allows up to 10 EX4300 switches to be interconnected and managed as a single device, delivering a scalable, pay-as-you-grow solution for expanding network environments. The EX4300 switches can be interconnected over multiple 40GbE quad small form-factor pluggable plus (QSFP+) transceiver ports to form a 320 gigabit per second (Gbps) backplane. Flexible 1GbE and 10GbE uplink options are also available, enabling high-speed connectivity to aggregation- or core-layer switches which connect multiple floors or buildings.prove productivity.
Full specifications (PDF)
Interfaces/Ports
Total Number of Network Ports:
48
Token Ring Port:
No
LRE Port:
No
Bypass:
No
Modular:
No
Management Port:
Yes
USB:
Yes
Number of PoE+ (RJ-45) Ports:
48
Stack Port:
No
Port/Expansion Slot Details:
  • 48 x Gigabit Ethernet Network
  • 4 x 40 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
4
Expansion Slot Type:
QSFP+
Network & Communication
Layer Supported:
3
Management & Protocols
Manageable:
Yes
Management:
  • Junos OS CLI
  • Web-based Management
  • VLAN
  • QoS
  • DHCP
  • SNMP v1, v2c, v3
  • RMON 1, 2, 3, 9
  • MIB
  • Telnet
Memory
Standard Memory:
2 GB
Memory Technology:
DRAM
Flash Memory:
2 GB
Power Description
PoE (RJ-45) Port:
No
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
  • Rack-mountable
  • Desktop
Height:
1.7"
Width:
17.4"
Depth:
16.4"
Weight (Approximate):
13.01 lb
Miscellaneous
Package Contents:
  • EX4300-48P Ethernet Switch
  • AC Power Supply
  • 2 x Fan Modules
Certifications & Standards:
IEEE Standards:
  • 802.1p
  • 802.1Q
  • 802.1X
  • 802.1ak
  • 802.3
  • 802.3u
  • 802.3ab
  • 802.3z
  • 802.3ae
  • 802.3ba
  • 802.3af
  • 802.3at
  • 802.3x
  • 802.3ah
Safety:
  • UL-UL60950-1
  • C-UL to CAN/CSA 22.2 No. 60950-1
  • TUV/GS to EN 60950-1
  • EN 60950-1
  • IEC 60950-1
EMC:
  • FCC 47CFR Part 15 Class A
  • EN 55022 Class A
  • ICES-003 Class A
  • VCCI Class A
  • AS/NZS CISPR 22 Class A
  • CISPR 22 Class A
  • EN 55024
  • EN 300386
  • CE
Environmentally Friendly:
Yes
Environmental Certification:
RoHS-6
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0832938063549
UPC: 832938063549
EAN: 0832938063549
UNSPSC: 43222612
