Juniper Networks EX4300-24T-S Network Switch

The Juniper Networks EX4300-24T-S Network Switch has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Juniper Networks EX4300 - EX4300, Chassis, 24-Port 10/100/1000 BaseT (No Power Supply or Fan Included)
  • Layer 3 Switch provides dependable and powerful connectivity for maximum usability
  • Features 24 networking ports to establish large network
  • Built-in power supply to ensure all components are being supplied with accurate voltage
  • Can work as layer 3 routing for scalable network design
  • Rack-mountable form factor for your convenience and simplicity of usage
  • Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
  • Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
  • 2 GB memory for smooth connectivity with multiple networks
Read More

Need a different version? See all Juniper EX4300 Network Switches

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Juniper Networks EX4300-24T-S Network Switch
Juniper Networks EX4300-24T-S Network Switch Juniper Networks EX4300-24T-S Network Switch
Juniper Networks EX4300-24T-S Network Switch
Juniper Networks EX4300-24T-S Network Switch
Full specifications (PDF)
Juniper EX4300 Network Switch Model Overview
The Juniper Networks EX4300 line of Ethernet switches delivers the performance and scale required for both campus and data center Gigabit Ethernet (GbE) access switch deployments. Combined with Juniper’s market leading Virtual Chassis technology, the EX4300 scales up to 10 members, delivering the high availability and plug-and-play scale that businesses demand. Combining compact, pay-as-you-grow economics and low power and cooling with the performance, availability, and port densities of chassis-based platforms, the EX4300 with Virtual Chassis technology enables businesses to deploy with speed and agility to increase revenue and improve productivity.
Juniper Networks EX4300-24T-S Network Switch Overview
The Juniper Networks EX4300 line of Ethernet switches with Virtual Chassis technology delivers the highperformance networking solution that high-performance businesses demand. Combining the compact, pay-as-you-grow economics and low power and cooling requirements of stackable switches with the performance, availability, and port densities of chassis-based platforms, the EX4300 enables businesses to deploy innovative new technologies that increase revenue and improve productivity.
Full specifications (PDF)
Interfaces/Ports
Total Number of Network Ports:
24
Token Ring Port:
No
LRE Port:
No
Bypass:
No
Modular:
No
Management Port:
Yes
USB:
No
Number of Network (RJ-45) Ports:
24
Port/Expansion Slot Details:
24 x Gigabit Ethernet Network
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
I/O Expansions
Number of Total Expansion Slots:
1
Expansion Slot Type:
Uplink Module
Shared SFP Slot:
No
Network & Communication
Layer Supported:
3
Management & Protocols
Manageable:
Yes
Management:
  • VLAN
  • QoS
  • Web-based Management
  • SNMP v1, v2c, v3
  • RMON (RFC 2819) Groups 1, 2, 3, 9
  • DHCP
  • Telnet
  • MIB
  • Command Line Interface (CLI)
Memory
Standard Memory:
2 GB
Memory Technology:
DRAM
Flash Memory:
2 GB
Power Description
PoE (RJ-45) Port:
No
Power Source:
Power Supply
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
  • Rack-mountable
  • Desktop
Height:
1.7"
Width:
17.4"
Depth:
16.4"
Weight (Approximate):
13 lb
Miscellaneous
Package Contents:
  • EX4300-24T-S Layer 3 Switch
  • Fan Modules
  • AC Power Supply
Certifications & Standards:
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1X
  • IEEE 802.1ak
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3z
  • IEEE 802.3ae
  • IEEE 802.3ba
  • IEEE 802.3af
  • IEEE 802.3at
  • IEEE 802.3x
  • IEEE 802.3ah

Safety Certifications:

  • UL-UL60950-1
  • C-UL to CAN/CSA 22.2 No. 60950-1
  • TUV/GS to EN 60950-1, Amendment A1-A4, A11
  • EN 60950-1 (2006 +A1:2009+A12:2010)
  • IEC 60950-1 (2005 +A1:2009)

Electromagnetic Compatibility Certifications:

  • FCC 47CFR Part 15 Class A
  • EN 55022 Class A
  • ICES-003 Class A
  • VCCI Class A
  • AS/NZS CISPR 22 Class A
  • CISPR 22 Class A
  • EN 55024
  • EN 300386
  • CE

NEBS:

  • GR-1089-Core: EMC and Electrical Safety for Network Telecommunications Equipment
Environmentally Friendly:
Yes
Environmental Certification:
RoHS-6
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0832938063518
UPC: 832938063518
EAN: 0832938063518
UNSPSC: 43222612
