Dataline Protection:
Fax/Modem
ITW Linx UP3P-235 UltraLinx 66 Block Accessory Model Overview
UP3P-235 UltraLinx 66 Block from ITWLinx features voice high-speed data 66 block surge protection with Sneak Current Protection, which protects against fires caused by overloads and power crosses. The Single Pair Protection method protects only the lines requiring protection. The Solid-state Protection automatically resets without user intervention and provides the fastest response to transient voltages by quickly diverting damaging surges to ground. They utilize replaceable 160mA PTC for voice/fax/modem line protection and 2 indicator lights for Protection and Ground Connection indications.
Technical Information
Physical Characteristics
Height:
2.6"
Width:
1.9"
Depth:
0.4"
Weight (Approximate):
0.64 oz
Miscellaneous
Additional Information:
Features:
- Streamlined Installation: Eliminate redundant cross-connects by adding protection directly at the 66 Block. Press fit protectors to the block and attach the ground bar to the protectors
- Ideal for Retrofit Applications: Just remove the bridging clips from the block and replace them with the UltraLinx Protector, add the ground connection and the pair is protected!
Product Specifications:
- Clamping: 235V
- Recommended Grounding Impedance: Less then 0.5 Ohm
- PTC Rating: 160mA (8-10 Ohms)
- Auto-Resettable: Yes
- Capacitance: Less then 50pF
- Agency Approval: UL 497A (Secondary)
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN:
0790237002402, 0818271438091, 0995478741749
UPC:
790237002402, 818271438091, 995478741749
EAN:
0790237002402, 0818271438091, 0995478741749
UNSPSC:
39121610
Get help from a Barcoding Expert!
The ITW Linx UP3P-235 Surge Protector is also known as
ILX-UP3P235
