Intermec SR61HD DPM – Barcode Scanner

Part Number: SR61TDPM-USB001
Model: SR61HD DPM
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Form Factor
Handheld
Scanner Type
CCD, Imager

Product Description:

  SR61THD DPM Ind High Dens Area Im USB K
Explore all Intermec SR61HD DPM Barcode Scanners
Add to Quote
Intermec SR61TDPM-USB001 Barcode Scanner
Intermec SR61TDPM-USB001 Barcode Scanner
Intermec SR61TDPM-USB001 Barcode Scanner
Intermec SR61TDPM-USB001 Barcode Scanner Intermec SR61TDPM-USB001 Barcode Scanner Intermec SR61TDPM-USB001 Barcode Scanner
Full specifications (PDF)

Intermec SR61HD DPM Barcode Scanner Model Overview

The Intermec SR61HD DPM handheld scanner is a customized variant of the SR61 family, capable of scanning high density bar codes and direct part marks commonly used to track assets in defense, aerospace, automotive, pharmaceutical, and telecommunications industries. Since this scanner is built on a common hardware platform, it is a much more cost-effective solution for scanning direct part marks when compared to specialized, purpose-built devices.
Intermec SR61TDPM-USB001 Barcode Scanner Overview

Reliably scan direct part marks applied with a variety of manufacturing processes: dot peening, chemical etching, laser etching, casting, engraving or stenciling-while still providing snappy performance on standard bar codes.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

1D:

  • Codabar
  • Codablock
  • Code 11
  • Code 128 (GS1-128)
  • Code 39
  • Code 93/93i
  • EAN/UPC
  • GS1 DataBar Expanded
  • GS1 DataBar Limited
  • GS1 DataBar Omni-Directional
  • GS1 DataBar Stacked
  • Interleaved 2 of 5
  • Matrix 2 of 5
  • Macro PDF
  • Micro PDF
  • MSI
  • PDF417
  • Plessey
  • Standard 2 of 5
  • Telepen
  • TLC39

2D:

  • Aztec
  • DataMatrix
  • GS1 Composite
  • MaxiCode
  • QR Code

Postal:

  • Australian Post
  • BPO
  • Canada Post
  • Dutch Post
  • Infomail
  • Intelligent Mail
  • Japan Post
  • Planet
  • Postnet
  • Sweden Post
Image Sensor Type:
Imager
Depth of Field:
  • 2.17" - 3.54"@3mil - Code 39
  • 1.97" - 4.13"@4mil
  • 1.97" - 4.72"@5mil
  • 2.95" - 9"@20mil
  • 14.17"@1mil
  • 2.36" - 7.09"@EAN 100%
  • 1.97" - 4.92"@5mil - PDF417
  • 1.57" - 6.5"@10mil
  • 2.36" - 8.07"@15mil
  • 2.17" - 4.13"@5mil - DataMatrix
  • 1.77" - 5.51"@10mil
Scan Pattern:
Omni-directional
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Height:
5.2"
Width:
2.8"
Length:
7.6"
Weight (Approximate):
11.29 oz
Miscellaneous
Additional Information:

USB Cable separate

Platform Supported:
PC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0682017495408
UPC: 682017495408
EAN: 0682017495408
UNSPSC: 43211701
