Intermec CV61A13XPAN80000 Data Terminal

The Intermec CV61A13XPAN80000 Data Terminal has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Intermec CV61 - Intermec CV61 Fixed Vehicle Mount Computer - Intel Atom 1.80 GHz - 3 GB RAM - 12.1" LED - XGA - 1024 x 768 - Wi-Fi - IEEE 802.11a/b/g/n - Serial - USB - Windows XP Professional Edition
Discontinued Need Assistance?
Add to Quote
Intermec CV61 Data Terminal Model Overview
The Intermec CV61 is a workhorse among vehicle mount mobile computers. Sped by a powerful 1.8 GHz Intel Atom processor, the Intermec CV61 features a choice of Windows 7 Professional or Windows XP operating systems. The integrated 9-60 VDC power supply works as a standalone system to power your device, lowering your installation costs and providing back-up even when your forklift battery is down. The Intermec CV61 is designed to integrate with your network security, management systems and your corporate standards. comprehensive network options include 802.11 a/b/g/n with Cisco CCXv4 certification and integrated EDR 2.1 Class 1.5 Bluetooth for best-in-class wireless range, roaming reliability and security. The Intermec CV61 exclusive device health reporting capability provides unparalleled insight to allow mobile workers and IT administrators to monitor and prevent issues related to scanning, communications and battery life, before they impact operations.
Intermec CV61A13XPAN80000 Data Terminal Overview
Combining next generation technology with a smart design that makes migrating from legacy vehicle-mount computers easy, the CV61 not only integrates seamlessly with the infrastructure you have in place today but provides you the room to grow well into the future.
Technical Information
Connectivity Technology:
Wireless
Processor & Chipset
Processor Manufacturer:
Intel
Processor Type:
Atom
Processor Speed:
1.80 GHz
Memory
Standard Memory:
3 GB
Storage
Hard Drive Capacity:
20 GB
Display & Graphics
Screen Size:
12.1"
Graphics Modes:
XGA
Display Screen Type:
LED
Touchscreen:
Yes
Display Resolution:
1024 x 768
Network & Communication
Antenna Form Factor:
No
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n
Interfaces/Ports
Network (RJ-45):
Yes
Serial:
Yes
USB:
Yes
Microphone:
Yes
PS/2 Port:
Yes
Headphone:
Yes
CANbus:
Yes
Built-in Devices
Built-in Devices:
  • Bluetooth
  • Speaker
Software
Operating System:
Windows XP Professional Edition
Physical Characteristics
Height:
10.8"
Width:
13.5"
Depth:
3.3"
Weight (Approximate):
11.46 lb
Miscellaneous
Certifications & Standards:
  • CCXv4
  • IP66
  • MIL STD 810F
Safety:
  • UL 60950-1
  • CSA C22.2 no. 60950-1
  • EN 60950-1
  • IEC 60950-1
Emissions:
  • FCC Part 15B-Class A
  • ICES-003-Class A
  • EN 55022-Class A (CISPR22)
  • EN 301 489-17
  • AS/NZS 3548-Class A (CISPR22)
Immunity:
  • EN 55024
Radio:
  • FCC Part 15C
  • IC RSS210, 102
  • EN 300 328
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211505
Questions? Get Help from
a Mobile Expert!

What is your operating system?

The Intermec CV61A13XPAN80000 Data Terminal is also known as INT-CV61A9 or CV61A13XPAN80000.
