Ingenico ISC480-USSCN53A Payment Terminal
Ingenico Parts Accessory Model Overview
Frequently Asked Questions
What display size and resolution does the Ingenico ISC480 offer?
The ISC480 features a 7-inch widescreen multimedia touchscreen with 800 x 480 resolution (16:9 aspect ratio) and 262,000 colors (18-bit). The display uses projected capacitive technology and supports both finger and stylus touch input, making it ideal for interactive customer transactions.
What payment methods can the ISC480 accept?
The ISC480 accepts multiple payment methods including magnetic stripe cards (triple track ISO 1, 2, 3 with dual heads), EMV smart cards (Level 1, rated for 500,000 insertions), and contactless payments via integrated or external antenna options. This multi-method capability allows merchants to accept virtually any preferred electronic payment from customers.
What are the processor and memory specifications for the ISC480?
The ISC480 is powered by a Thunder ARM9 main processor running at 450 MIPS and a Booster ARM7 crypto processor at 50 MIPS. It includes 128 MB Flash NAND and 128 MB DDR2 RAM internally, with support for microSD cards up to 32 GB for external storage expansion.
What connectivity options are available on the ISC480?
The ISC480 offers comprehensive connectivity including USB 2.0 (both device and dual host ports), RS232 serial, 10/100 Ethernet, and optional Mini-HDMI video output. It also supports Power over Ethernet (POE) compliant with 802.3af standards, providing flexible deployment options for retail environments.
Does the ISC480 support signature capture?
Yes, the ISC480 includes full signature capture capability with support for up to 1 million signatures. The non-mechanical stylus combined with the projected capacitive touchscreen provides a reliable and durable solution for capturing customer signatures on transactions.
What operating system does the ISC480 run?
The ISC480 runs on Telium 2 operating system and includes 2 Secure Access Module (SAM) slots for enhanced security. This platform provides access to over 800 Ingenico services and applications while supporting rapid development for custom retail solutions.
