Ingenico IMP657-USSCN22A Payment Terminal
Ingenico Parts Accessory Model Overview
Frequently Asked Questions
What payment card readers does the Ingenico IMP657 support?
The Ingenico IMP657 includes a triple-track magnetic stripe reader and an EMV Level 1 & 2 approved smart card reader, enabling secure acceptance of both magnetic stripe and chip-based payment cards. This dual-reader capability ensures compatibility with legacy and modern payment methods across your transaction environment.
What connectivity options are available on the IMP657 payment terminal?
The IMP657 offers multi-protocol connectivity including RS232, RS485, USB/Powered USB on the host port, RS232 on the auxiliary port, and Ethernet support. This flexible connectivity allows seamless integration with existing POS systems, cash registers, and network infrastructure in retail and hospitality environments.
Is the Ingenico IMP657 PCI compliant and secure for payment processing?
Yes, the IMP657 is PCI PED approved and implements industry-standard security protocols including DES and Triple DES PIN encryption, Code Authentication for secure application loading, and compliance with ANSI standards X3.92, X9.8, X9.9, X9.19, and X9.24. These security features protect cardholder data and ensure safe payment transactions.
Can the IMP657 capture customer signatures?
Yes, the IMP657 features a glass TFT color touchscreen with capacitive technology and an electronic pen specifically designed for signature capture. The glare-resistant display is sealed to withstand accidental liquid spillage, making it reliable for high-traffic retail and hospitality environments.
What is the memory configuration of the Ingenico IMP657?
The IMP657 includes standard memory of 2MB RAM and 8MB Flash, providing sufficient storage for payment applications and transaction processing. This configuration supports the Telium 2 operating system and typical point-of-sale functionality.
Does the IMP657 include a barcode reader?
Yes, this IMP657-USSCN22A model includes an integrated barcode reader, enabling product scanning and inventory lookup capabilities directly at the payment terminal. This integrated functionality streamlines checkout operations and reduces the need for separate scanning devices. Contact us today to verify barcode reader specifications and compatibility with your environment.
