Impinj IPJ-REV-R220-USA1M1 RFID Reader
Full specifications (PDF)
Impinj Speedway Revolution RFID Reader Model Overview
Key Features
- Autopilot Technology - Automatically senses and configures settings for optimal performance.
- Power over Ethernet (PoE) - Simplifies deployment and reduces operational costs.
- High Transmit Power - Capable of overcoming cable losses for enhanced readability.
- Dynamic Antenna Switching - Improves throughput by focusing on the antennas with the largest tag populations.
- Enterprise-Class Management - Seamless integration with leading software solutions.
Specifications
- Air Interface Protocol: EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
- Transmit Power: +10.0 to +30.0 dBm (PoE)
- Max Receive Sensitivity: -82 dBm
- Ports: 2 (R220) or 4 (R420) high-performance antenna ports
- Operating Temperature: -20 °C to +50 °C
- Environmental Sealing: IEC IP52
- Dimensions: 7.5 x 6.9 x 1.2 in (19 x 17.5 x 3 cm)
- Weight: 1.5 lbs (24.5 oz)
- Power Consumption: Idle: 3W, Typical: 11.5W, Max: 15W
Recommended Accessories
Category
- Cables, Connectors, and Adapters (1)
- Far Field RFID Antenna (4)
- RFID Antenna Accessories (3)
- RFID Reader Accessories (16)
- Spare Parts (11)
Recommended Accessories for Model: Impinj IPJ-REV-R220-USA1M1 RFID Reader
Top Cables, Connectors, and Adapters Purchased With Impinj IPJ-REV-R220-USA1M1
-
Impinj IPJ-A4000-000 Cables, Connectors, and AdaptersSpeedway Revolution R220/R420 Console Cable for connecting to the Impinj RShell management console through the serial console port on the Speedway Revolution reader.Item on backorder — chat for lead time$42.00
Top Far Field RFID Antenna Purchased With Impinj IPJ-REV-R220-USA1M1
-
Impinj IPJ-A1000-USA RFID AntennaFar Field LHP Antenna (FCC) (10.1 x 10.1 x 1.4 in.) with 8ft pigtail cable.Item on backorder — chat for lead time$423.00 -
Impinj IPJ-A1001-USA RFID AntennaRFID Antenna, UHF, FCC, 10.1 x 10.1 x 1.4 inches, Far Field, Indoor, Right-Hand Polarized, Includes 8 Foot Pigtail Cable.Item on backorder — chat for lead time$423.00 -
Impinj IPJ-A1001-EU1 RFID AntennaFar Field RHP Antenna (ETSI) (10.1 x 10.1 x 1.4 in.) with 8ft pigtail cable.Item on backorder — chat for lead time$423.00
Top RFID Antenna Accessories Purchased With Impinj IPJ-REV-R220-USA1M1
-
Impinj IPJ-A3002-000 AccessoryImpinj Antenna Cable - SMA Male Antenna - RP-TNC Male Antenna - 6.56ftItem on backorder — chat for lead time$86.00 -
Impinj IPJ-A3004-000 AccessoryImpinj Antenna Cable - SMA Male - RP-TNC Male - 13.12ftItem on backorder — chat for lead time$108.00 -
Impinj IPJ-A3008-000 AccessorySMA to R-TNC cable 26ft, For use with Guardwall, Mini-Guardrail, Matchbox, and Threshold antennas).Item on backorder — chat for lead time$172.00
Top RFID Reader Accessories Purchased With Impinj IPJ-REV-R220-USA1M1
-
$45.00 -
Impinj IPJ-A4000-000 Cables, Connectors, and AdaptersSpeedway Revolution R220/R420 Console Cable for connecting to the Impinj RShell management console through the serial console port on the Speedway Revolution reader.Item on backorder — chat for lead time$42.00
-
$45.00
Top Spare Parts Purchased With Impinj IPJ-REV-R220-USA1M1
-
$45.00
-
$45.00
-
$45.00
