ID Tech WCR3297-700 Barcode Card Reader

Part Number: WCR3297-700
Model: Omni
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$169.34

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Magnetic Stripe Track Configuration
Triple Track
Magnetic Stripe Track Number
Track 2Track 1Track 3
Minimum Swipe Speed
3 in/s
Maximum Swipe Speed
60 in/s

Product Description:

  ID TECH Omni WCR32 Magnetic Stripe Reader - Triple Track - 60 in/s - Wiegand - Black
Explore all ID Tech Omni Barcode Card Readers
Add to Quote
ID Tech WCR3297-700 Barcode Card Reader
ID Tech WCR3297-700 Barcode Card Reader
ID Tech WCR3297-700 Barcode Card Reader ID Tech WCR3297-700 Barcode Card Reader
Full specifications (PDF)

ID Tech Omni Barcode Card Reader Model Overview

The ID Tech Heavy Duty Omni Barcode Reader. In addition to rugged housing, the Omni Barcode Reader has a metal base with tapped holes and rubber feet, and can be Velcro mounted. Multi-colored LED (not on TTL). The cable can exit at the end, side or straight down. Options include visible red or infrared barcode scanning; as well as TTL, RS-232, keyboard wedge (AT/XT, PS/2, or Mac), Weigand or USB interface options.
ID Tech WCR3297-700 Barcode Card Reader Overview

The Omni WCR32 Magnetic Stripe Reader is originally designed for the demanding access control and time and attendance markets. Its die cast metal base, stainless steel wear plate, and impact resistant housing make it ideal for the growing market of self service and unattended applications. It reads up to three tracks of magnetic information with a single swipe in either direction.

Full specifications (PDF)
Technical Information
Magnetic Stripe Track Configuration:
Triple Track
Magnetic Stripe Track Number:
  • Track 2
  • Track 1
  • Track 3
Minimum Swipe Speed:
3 in/s
Maximum Swipe Speed:
60 in/s
Number of Swipes (Head Life):
1000000
Interfaces/Ports
Wiegand:
Yes
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Product Color:
Black
Height:
1.4"
Width:
2.1"
Length:
5"
Weight (Approximate):
1.40 lb
Miscellaneous
Additional Information:
  • Reads Both Magnetic Stripe And Barcode Media
  • Superior Reading Of High Jitter, Scratched, And Worn MagStripe Cards
  • Metal Base Can Be Securely Mounted With Cable Exits From Side, End, Or Bottom
  • Weatherproof Sealed Or Extended Temperature
  • Iinfrared Bar Code Reader Option
Item Numbers
GTIN: 0078213903326, 0682017460208
UPC: 078213903326, 682017460208
EAN: 0078213903326, 0682017460208
UNSPSC: 43211702
