The ID Tech Heavy Duty Omni Barcode-Stripe Reader can read barcodes and magnetic stripe reader. In addition to rugged housing, the Omni Barcode-Stripe Reader has a metal base with tapped holes and rubber feet, and can be Velcro mounted. Multi-colored LED (not on TTL). The cable can exit at the end, side or straight down. Options include visible or infrared barcode scanning; as well as TTL, RS-232, keyboard wedge (AT/XT, PS/2, or Mac), Weigand or USB interface options.
ID Tech WCR3237-612C Barcode Card Reader Overview
The Omni reads up to 3 tracks of information with a single swipe in either direction. In combination, the same Omni unit can read both barcode and MagStripe media. It scans barcodes printed on paper, card stock, or plastic. An infrared option is available for security-based applications, where barcodes are over-printed to prevent duplication. The data outputs are TTL, RS232, keyboard wedge, USB-KB, USB-RS232, and Wiegand interfaces.
The Omni's output can be formatted with terminating characters, special preamble and/ or postamble character strings, and special parsing to match the data format expected by the terminal. These settings are programmed into the reader and stored in nonvolatile memory.
The Omni reader is designed for demanding applications, such as for access control or in self-service kiosks. Its die-cast metal base, stainless steel wearplate, and impact-resistant housing make it ideal for stand-alone, high-volume applications. Its metal base can be securely mounted with screws, and cable exits are available at the side, end, or bottom of the unit. Weatherproof, sealed, or extended temperature versions are available for use in harsh environments.
