ID Tech IDKA-234133B Keyboards

Part Number: IDKA-234133B
Model: VersaKey
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Keys
105
Keyboard/Keypad Cable Length
4.92 ft
Keyboard/Keypad Host Interface
USB
Built-in Devices
Magnetic Stripe Reader

Product Description:

  ID TECH Versakey POS Keyboard - 105 Keys - Magnetic Stripe Reader - USB - Black
Explore all ID Tech VersaKey Keyboards
Add to Quote
ID Tech IDKA-234133B Keyboards
ID Tech IDKA-234133B Keyboards
ID Tech IDKA-234133B Keyboards ID Tech IDKA-234133B Keyboards
Full specifications (PDF)

ID Tech VersaKey Keyboards Model Overview

The VERSAKEY POS Keyboard with MagStripe Reader offers a reliable and efficient solution for high-volume transaction environments. Featuring an enhanced layout with separated function keys, control keys, cursor keys, and a full numerical keypad, this keyboard is designed for user comfort and productivity. Built to withstand over 10 million key operations and 1 million swipes, it ensures durability that businesses can count on. The integrated MagStripe reader enhances its versatility and is configurable to meet specific software requirements, making it an ideal tool for any retail operation.


Key Features
  • Durable design: Survives more than 10 million key presses and 1 million swipes.
  • Integrated MagStripe reader: Provides configurable output to meet host application needs.
  • Customizable layout: Offers various country-specific key layouts.
  • Multiple interface options: Available with USB or PS/2 connections.
  • Standard warranty: 3-year warranty for added peace of mind.

Specifications
  • Power Requirement: +5.0 VDC ±10%, 60mA Max.
  • Operating Temperature: 0°C to 40°C (32°F to 104°F).
  • Storage Temperature: -20°C to 40°C (-4°F to 104°F).
  • Drop Resistance: 610 mm (24") drop, 1 corner and 2-side lines.
  • Size: 469.9 mm (L) x 203.9 mm (W) x 42.8 mm (H).
  • Weight: Approx. 1.2 kg.
  • Material: High Impact PS, meets flammability spec. UL94HB.
  • Keyboard Operating Life: 20,000,000 keystrokes.
  • MagStripe Reader Life: 1,000 cycles.
  • Swipe Speed: 3 to 60 inches per second, bi-directional.
  • Card Thickness: 0.015 to 0.045 inches.
ID Tech IDKA-234133B Keyboards Overview
Versatile, Full Function POS Keyboard

VersaKey features an enhanced layout keyboard with a full featured MagStripe card reader. The keyboard layout provides separated function keys, control keys, curser keys, and a full numerical input keypad. There are also many country specifi c key layouts available.

Versatile MagStripe Reader

VersaKey's integrated MagStripe reader delivers the MagStripe data in the format needed. If the host computer's application software is expecting the MagStripe data in a particular order and format, the reader's output can be confi gured to output a simulated keyboard-entered data stream by rearranging data blocks, adding terminating characters and special preamble and/or postamble character strings to the decoded card data.

Durable Keyboard and Card Reader Combination

VersaKey is designed to provide the reliability needed for usage in repetitive and high volume operation. The unit is proven to endure more than 10 million key operations and 1 million swipes. Standard warranty of 3 years provides confi dence that the unit is built to last.

Intelligent Interface Options

VersaKey is available with a USB or PS/2 interface depending on the user's needs. For convenience, the USB version also comes with two additional USB Hub connections. Both USB and PS/2 keyboard versions have only one communication cable. The keyboard data and the MagStripe data are output from the one cable. The MagStripe data transmitted through the keyboard cable and it appears to originate directly from the keyboard.
Full specifications (PDF)
Keyboard/Keypad
Total Number of Keys:
105
Keyboard/Keypad Cable Length:
4.92 ft
Interfaces/Ports
Keyboard/Keypad Host Interface:
USB
Built-in Devices
Built-in Devices:
Magnetic Stripe Reader
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Product Color:
Black
Product Material:
High Impact Polystyrene (HIPS)
Height:
1.7"
Width:
8"
Length:
18.5"
Item Numbers
GTIN: 0009835160606, 0783555115664
UPC: 009835160606, 783555115664
EAN: 0009835160606, 0783555115664
UNSPSC: 43211706
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The ID Tech IDKA-234133B Keyboards is also known as IDT-IDKA234133B or IDKA234133B.
