HP P53564-001 Servers

Part Number: P53564-001
Model: Parts
$8,331.00
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Processors Supported
2
Number of Processors Installed
1
Processor Type
Xeon Silver
Processor Generation
4th Gen

Product Description:

  Servers, HP, ML350 GEN11 4410Y 1P 32G 4LFF SVR PL-SY

HP Parts Accessory Model Overview

Products and parts from HP.
HP P53564-001 Servers Overview

HPE ProLiant ML350 Gen11

Provide most powerful and storage flexibility 2P tower server with rackable chassis design for various environments, and delivers exceptional compute performance, security, reliability, and expandability. Design to fulfill with wide range workloads for small offices, remote and branch offices of large enterprises, growing SMBs and data centers. HPE ProLiant ML350 Gen11 server is an excellent choice to accelerate your growing business.

Processor
Number of Processors Supported:
2
Number of Processors Installed:
1
Processor Type:
Xeon Silver
Processor Generation:
4th Gen
Processor Model:
4410Y
Processor Core:
Dodeca-core (12 Core)
Processor Speed:
2 GHz
Cache:
30 MB
Chipset
Chipset Manufacturer:
Intel
Chipset Model:
C741
Memory
Standard Memory:
32 GB
Maximum Memory Supported:
8 TB
Memory Technology:
DDR5 SDRAM
Memory Clock Speed:
4.80 GHz
Error Checking:
ECC
Total Number of Memory Slots:
32
Number of Occupied Memory Slots:
1
Signal Processing:
Registered (Buffered)
Controllers
Controller Type:
  • Serial Attached SCSI (SAS)
  • Serial ATA
Controller Model:
VROC
RAID Supported:
Yes
I/O Expansions
Number of Total Expansion Bays:
4
Number of 3.5" Bays:
4
Number of LFF Bays:
4
Hot Swappable Bays:
Yes
Total Number of Expansion Slots:
4
PCI Express Details:
4 x8 PCIe 5.0 slots
Riser Card:
4 x8 PCIe 5.0 slots with primary riser cage
Display & Graphics
Graphics Memory Capacity:
16 MB
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
Total Number of USB Ports:
5
Number of USB 2.0 Ports:
1
Network (RJ-45):
Yes
Number of Network (RJ-45) Ports:
4
VGA:
Yes
Number of VGA Ports:
1
Remote Management:
Yes
Remote Management Controller:
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced and HPE OneView Advanced (require licenses)
DisplayPort:
Yes
Number of DisplayPorts:
1
Operating System
Operating System Supported:
  • Red Hat Enterprise Linux
  • SuSE Linux Enterprise Server
  • Ubuntu
  • Citrix XenServer
  • Windows Server
  • Oracle Linux
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Number of Power Supplies Supported:
2
Number of Power Supplies Installed:
1
Plug/Connector Type:
C13/C14
Maximum Power Supply Wattage:
800 W
Hot Swappable Power Supply:
Yes
Power Source:
Power Supply
Physical Characteristics
Form Factor:
Tower
Rack Height:
4U
Height:
18.2"
Width:
6.9"
Depth:
28"
Weight (Approximate):
94.91 lb
Miscellaneous
Package Contents:
  • ProLiant ML350 G11 Server
  • 6-foot IEC C-13/C-14 Jumper Cord
Security Features:
  • UEFI Secure Boot and Secure Start support
  • Immutable Silicon Root of Trust
  • FIPS 140-3 validation (iLO 6 certification in progress)
  • Common Criteria certification (iLO 6 certification in progress)
  • Configurable for PCI DSS compliance
  • Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
  • Support for Commercial National Security Algorithms (CNSA)
  • Tamper-free updates -- components digitally signed and verified
  • Secure Recovery -- recover critical firmware to known good state on detection of compromised firmware
  • Ability to rollback firmware
  • Secure erase of NAND
  • TPM (Trusted Platform Module) 2.0
  • Front bezel key-lock feature -- standard, available in both Tower and Rack models
  • Padlock slot, standard
  • Kensington Lock slot, standard
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
3 Year
Additional Warranty Information:

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Item Numbers
GTIN: 0190017594293
UPC: 190017594293
EAN: 0190017594293
UNSPSC: 43211501

Frequently Asked Questions

The HP P53564-001 Server is available with either an Intel Celeron 2.0-GHz or Intel Pentium 4 2.0-GHz processor, both featuring a 400-MHz front side bus. These processors are paired with the Intel 845GV chipset to deliver reliable performance for point-of-sale and server applications.

The HP P53564-001 Server comes standard with 128-MB of 333-MHz PC2700 DDR memory and features 2 DIMM slots, allowing expansion up to 2 GB of DDR memory. This expandability ensures your system can grow with your operational needs.

The HP P53564-001 includes a 40-GB 5400 rpm SMART III Ultra ATA/100 hard drive as standard, with 1 internal 3.5-inch ATA hard drive bay. You can also choose from 48x CD-ROM, 16x/40x DVD-ROM, or 48x/32x/48x CD-RW optical drives, plus an optional 1.44-MB diskette drive for legacy support.

The HP P53564-001 Server provides comprehensive connectivity with 1 parallel port, 4 standard RS232 serial ports (individually configurable to powered 5V or 12V), 6 USB 2.0 ports (4 powered), 1 PS/2 keyboard port, 1 PS/2 mouse port, and 1 VGA adapter. It also features an Intel Pro 100/VM network interface card for reliable Ethernet connectivity.

The HP P53564-001 Server includes physical security provisions such as Kensington Cable Lock provision and a hood cover security feature to protect your hardware from unauthorized access. These features make it suitable for secure retail and warehouse environments.

The HP P53564-001 Server comes pre-installed with your choice of Microsoft Windows XP Professional with Service Pack 1a, Microsoft Windows XP Embedded with Service Pack 1, or Microsoft Windows 2000 with Service Pack 4. Contact us today to discuss which operating system best fits your warehouse or retail operations.
