HP A1X77AA#ABA Touchscreen

The HP A1X77AA#ABA Touchscreen has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
HP L6017tm - HP L6017tm 17" LCD Touchscreen Monitor - 5:4 - 30 ms - 17" Class - Projected CapacitiveMulti-touch Screen - 1280 x 1024 - SXGA - Adjustable Display Angle - 800:1 - 225 Nit - LED Backlight - Speakers - DVI - USB - VGA - DisplayPort - Jack Black - Ecolabel, IT Eco Declaration, RoHS, WEEE, CECP, China Energy Label (CEL) - 3 Year
  • LED backlight enhances the display performance to deliver an outstanding color range and contrast ratio
  • The 800:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
  • The 225 Nit brightness gives an exceptionally visible display for clear and consistent on-screen pictures
  • Multi-touch activation can be performed with the Projective Capacitive touchscreen technology i.e. you can input from two fingers at a time.
  • VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
Read More

Need a different version? See all HP L6017tm Touchscreens

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
HP A1X77AA#ABA Touchscreen
HP A1X77AA#ABA Touchscreen HP A1X77AA#ABA Touchscreen
HP A1X77AA#ABA Touchscreen
HP A1X77AA#ABA Touchscreen
Full specifications (PDF)
HP L6017tm Touchscreen Model Overview
Retail touch displays designed for increased usability, superior durability, and a modernized appearance that seamlessly integrate into retail environments. The sleek and stylish HP L6017tm 17 inch Retail Touch Monitors are designed for increased performance, enhanced usability, and outstanding durability in retail environments. Both monitors feature multi-touch Projected Capacitive touch technology for a familiar, intuitive experience similar to smartphone and tablet devices.
HP A1X77AA#ABA Touchscreen Overview
The sleek and stylish flush-bezel HP L6017tm 17-inch Retail Touch Monitor is designed for increased performance, enhanced usability, and outstanding durability in retail and hospitality environments

  • The 17-inch diagonal standard aspect ratio monitor features multi-touch Projected Capacitive touch technology, which offers a familiar, intuitive experience similar to smartphone and tablet devices.
  • The chemically-strengthened flush-glass design is durable and easy-to-clean, helps provide protection from dust and spilled liquids, and creates a modernized appearance that complements a range of environments and HP POS systems.
  • The display supports internal integration with optional peripherals such as a Magnetic Stripe Reader, Biometric Fingerprint Reader or Webcam for enhanced product functionality that maximizes valuable counter space. Each sold separately.
  • The White LED industrial panels deliver improved brightness, a high contrast ratio, extended product life, and are energy efficient.
  • The display features an industry-standard 100-mm VESA pattern that delivers mounting flexibility in space-constrained environments. Mounting hardware sold separately.
Full specifications (PDF)
Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Screen Surface:
  • Anti-glare
  • Anti-static
Response Time:
30 ms
Aspect Ratio:
5:4
Horizontal Viewing Angle:
170°
Vertical Viewing Angle:
160°
Adjustable Display Angle:
Yes
Adjustable Display Height:
Yes
Adjustable Display Pivot:
No
Backlight Technology:
LED
HDCP Supported:
Yes
Features:
Security Lock
Adjustable Stand Height:
Yes
Video
Maximum Resolution:
1280 x 1024
Standard Refresh Rate:
60 Hz
Contrast Ratio:
800:1
Brightness:
225 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Projected Capacitive
Multi-touch Screen:
Yes
Interfaces/Ports
DVI:
Yes
USB:
Yes
USB Standard:
USB 2.0
VGA:
Yes
DisplayPort:
Yes
Built-in Devices
Built-in Devices:
  • USB Hub
  • Speaker
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
39 W
Standby Power Consumption:
1 W
Off-Mode Power Consumption:
500 mW
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Color:
Jack Black
Height:
13.3"
Width:
15.2"
Depth:
2.3"
Height with Stand:
16.65"
Width with Stand:
15.20"
Depth with Stand:
11.14"
Weight (Approximate):
10.36 lb
Weight with Stand (Approximate):
14.99 lb
Miscellaneous
Package Contents:
  • L6017tm 17-inch Retail Touch Monitor
  • 1 x VGA Cable
  • 1 x DisplayPort Cable
  • 1 x DVI-D Cable
  • 1 x USB Cable
  • Audio Cable
  • Power Cord
  • Printed Documentation
  • CD
Certifications & Standards:
  • CB
  • CE
  • UL
  • CSA
  • FCC
  • ICES
  • VCCI
  • BSMI
  • CCC
  • SEPA
  • CTick
  • S-Mark
  • ISO 11469
  • ISO1043
Platform Supported:
PC
Environmentally Friendly:
Yes
Environmental Certification:
  • Ecolabel
  • IT Eco Declaration
  • RoHS
  • WEEE
  • CECP
  • China Energy Label (CEL)
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0995476982700
UPC: 995476982700
EAN: 0995476982700
UNSPSC: 43211903
Questions? Get help from
a POS Expert!

What is your POS application?

The HP A1X77AA#ABA Touchscreen is also known as A1X77AA#ABA
