Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
- Aztec Code
- Chinese Sensible Code
- Code One
- Data Matrix
- GM Code
- MaxiCode
- MicroPDF417
- Micro QR Code
- PDF417
- QR Code
Image Sensor Type:
CMOS
Scanning Distance:
9.60"
Field of View (Horizontal):
42°
Field of View (Vertical):
28°
Reading Angle (Skew):
60°
Reading Angle (Pitch):
60°
Reading Angle (Roll):
360°
Minimum Print Contrast:
25%
Maximum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (PDF417):
6.7 mil
