Bring digital content creations to life with Intel Xeon Gold processors, which have up to 24 cores per processor for peak performance across a broad range of workstation applications, from entry CAD to video editing.
What processor does the HP 5YT00AA workstation use?
The HP 5YT00AA features an Intel Xeon Gold (2nd Gen) 6234 octa-core processor running at 3.30 GHz with a 24.75 MB L3 cache, 64-bit processing capability, and a maximum overclocking speed of 4 GHz. This processor operates at 130W and supports 16 threads across 8 cores, making it suitable for demanding workstation applications.
How much memory can this HP workstation support?
The HP 5YT00AA supports up to 128 GB of DDR4-2666 ECC SDRAM or 128 GB of DDR4-2666 non-ECC SDRAM with transfer rates up to 2666 MT/s. The system includes 4 DIMM slots for flexible memory configuration to meet your performance requirements.
What storage options are available for the HP 5YT00AA?
This workstation offers multiple internal storage configurations including SATA drives (500 GB to 6 TB at 7200 rpm), SATA SSDs (256 GB to 2 TB), Intel Optane SSD 905P (280 GB to 480 GB), HP Z Turbo Drive G2 PCIe NVMe SSD (256 GB to 1 TB), and SATA SED options. The system has one 2.5" bay, one 3.5" bay, and two M.2 NVME 2280 SSD bays internally, plus one external 3.5" HDD bay.
What graphics options does the HP 5YT00AA support?
The HP 5YT00AA offers integrated graphics with Intel UHD Graphics 630 or Intel UHD Graphics P630, as well as dedicated 3D graphics options including NVIDIA Quadro P400 (2 GB GDDR5), NVIDIA Quadro P620 (2 GB GDDR5), NVIDIA Quadro P1000 (4 GB GDDR5), or AMD Radeon Pro WX 3100 (4 GB GDDR5). This flexibility allows you to choose graphics performance based on your specific workload needs.
What connectivity and expansion options does this workstation provide?
The HP 5YT00AA includes comprehensive connectivity with integrated Intel LAN, 2 DisplayPort 1.2 connections, 1 DVI-I single link port, and multiple USB ports (2 USB 2.0 front, 4 USB 3.0 back, plus USB 3.1 Gen 2 Type-C charging). Expansion slots include 2 M.2 PCIe 3 x4, 1 PCIe Gen 3 x16, 2 PCIe 3 x1, and 2 PCIe 3 x4 slots, with optional Flex I/O available.
Is the HP 5YT00AA compatible with vPro technology?
Yes, the HP 5YT00AA features Intel vPro support with an Intel C246 chipset. For full vPro functionality, the system requires Windows, a vPro-supported processor, vPro-enabled chipset, vPro-enabled wired LAN card, and discrete TPM 2.0. Contact us today to discuss vPro configuration options for your specific security and management requirements.
