What processor does the HP 5YS98AA workstation use?
The HP 5YS98AA features an Intel Xeon Gold (2nd Gen) 6226 processor with 12 cores running at 2.70 GHz base speed, capable of overclocking to 3.70 GHz. This processor includes 19.25 MB L3 Cache, supports 64-bit processing, and operates at 125W with 24 threads for demanding workstation applications.
How much memory can the HP 5YS98AA support?
The HP 5YS98AA supports up to 128 GB of DDR4-2666 ECC SDRAM or 128 GB of DDR4-2666 non-ECC SDRAM with transfer rates up to 2666 MT/s. The system includes 4 DIMM slots for flexible memory configuration to meet your workstation requirements.
What storage options are available for the HP 5YS98AA?
We offer multiple internal storage configurations including SATA drives (500 GB to 6 TB at 7200 rpm), SATA SSDs (256 GB to 2 TB), Intel Optane SSD 905P (280 GB to 480 GB), and HP Z Turbo Drive G2 PCIe NVMe SSDs (256 GB to 1 TB). The workstation features one 2.5" bay, one 3.5" bay, and two M.2 NVME 2280 SSD bays internally, plus one external 3.5" HDD bay.
What graphics options does the HP 5YS98AA workstation offer?
The HP 5YS98AA provides integrated graphics with Intel UHD Graphics 630 or Intel UHD Graphics P630, or you can configure it with discrete entry-level 3D graphics including NVIDIA Quadro P400, P620, P1000, or AMD Radeon Pro WX 3100 with dedicated GDDR5 memory. Contact us today to select the graphics configuration that best fits your workflow.
What connectivity and expansion options does this workstation provide?
The HP 5YS98AA includes integrated Intel LAN networking, front USB ports (1x USB 2.0, 2x USB 3.0, 1x USB 3.1 Gen 2 Type-C), rear ports (2x DisplayPort 1.2, 4x USB 3.0, 2x USB 2.0, 1x RJ-45, audio connectors), and extensive expansion with 2x M.2 PCIe 3.0 x4 slots, 1x PCIe Gen 3 x16, and 2x PCIe 3.0 x1 slots. Optional Flex I/O connectivity is available from us for additional configuration flexibility.
Is the HP 5YS98AA compatible with Windows 10?
Yes, the HP 5YS98AA is compatible with Windows 10 Pro and Windows 10 IoT Enterprise 2019 LTSC. Please note that this workstation does not support Windows 8 or Windows 7, as per Microsoft's support policy for systems with 7th generation and forward Intel processors. Visit barcodesinc.com or contact us today for operating system licensing options.
