Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
-
Auto-discriminates all standard 1D codes (including GS1 DataBar linear codes)
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- QR Code
- Micro QR Code
Postal decode symbologies:
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
Stacked decode symbologies:
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- Macro PDF
- Micro PDF417
- UPC A/E Composites
Image Sensor Type:
Imager
Scan Pattern:
Omni-directional
Cable Type Included:
USB
Stand Included:
Yes
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
6.0 ft (1.8 m)
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
10 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
15 mil
Maximum Element Resolution (PDF417):
10 mil
