Honeywell – Barcode Label Printer – 300 dpi – Cutter

Part Number: EL3-00-1JG05Q0L
Model: Parts
3-year Premium Plus ($154.00)
No, stay at premium support package
$880.88
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Interface Options
Ethernet, USB, Serial
Print Resolution
300 dpi
Printer Options
Cutter
Display Type
LCD

Product Description:

  Barcode Label Printers, Honeywell, E-4305L Lg, 300dpi, 5ips, Lcd

Honeywell Parts Accessory Model Overview

Products and parts from Honeywell.
Honeywell EL3-00-1JG05Q0L Barcode Label Printer Overview
3 Dimensions of Value

The E-Class Mark III is a family of compact desktop thermal printers that are designed for a wide variety of industries and applications that require a reliable and cost effective barcode printer. Datamax-O'Neil applied its industrial printer expertise to provide customers with an entry level printer that has the features and reliability normally found in more expensive printers. The E-Class Mark III is affordable to own, easy to use and economical to operate.

We've made the E-Class Mark III thermal barcode printer easy to use with quick loading media and an interactive LCD screen. Users will also notice a substantial reduction in their daily operational costs thanks to the E-Class Mark III's larger media and ribbon roll capacity. The E-Class Mark III is one of the best values on the market. It is competitively priced with a proven design and reliable performance that will continue to operate long after other barcode printers have failed.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
5 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
4.16"
Barcode Symbology Supported:
  • Code 3 of 9
  • UPC-A
  • UPC-E
  • Interleaved 2 of 5
  • Code 128
  • EAN-13
  • EAN-8
  • HIBC
  • Codabar
  • Plessey
  • UPC 2 and 5 Digit Addendums
  • Code 93
  • POSTNET
  • UCC/EAN 128
  • K-Mart NON EDI
  • Telepen
  • UPS MaxiCode
  • FIM
  • PDF-417
  • Data Matrix
  • QR Code
  • Aztec Code
  • GS1 DataBar
  • TCIF
  • TLC 39
  • Micro PDF-417
Application/Usage:
Desktop
Features:
Mirror Printing
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
32 MB
Memory Technology:
DRAM
Flash Memory:
64 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Display & Graphics
Display Screen:
Yes
Display Screen Type:
LCD
Cutter
Cutter:
Yes
Media Types & Handling
Media Type:
  • Label
  • Tag
  • Gap
  • Notch
  • Black Bar
  • Fanfold
Media Sensor:
  • Transmissive Media Sensor
  • Reflective Media Sensor
  • Adjustable Media Sensor
Media Thickness:
10 mil
Maximum Roll Diameter:
7.20"
Maximum Label Width:
4.40"
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • PLE
  • PLB
Power Description
Power Source:
  • Battery
  • Power Adapter
Physical Characteristics
Color Family:
Gray
Product Color:
Warm Gray
Height:
9.6"
Width:
8"
Depth:
14"
Weight (Approximate):
7.70 lb
Miscellaneous
Platform Supported:
PC
Certifications & Standards:
Unicode
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108

Frequently Asked Questions

The Honeywell EL3-00-1JG05Q0L is a 300 DPI industrial desktop barcode label printer with a print speed of 5 inches per second and an LCD display for easy operation. This printer is designed for high-volume labeling applications in warehouse and logistics environments where reliable, professional-quality barcode labels are essential.

Yes, the Honeywell EL3-00-1JG05Q0L is purpose-built for warehouse and logistics applications requiring consistent, durable barcode label production. Its industrial-grade construction and 300 DPI resolution make it ideal for shipping labels, inventory tags, and asset tracking in demanding warehouse environments.

The Honeywell EL3-00-1JG05Q0L delivers 300 DPI print resolution, which provides sharp, scannable barcode quality suitable for retail, warehouse, and industrial applications. This resolution ensures reliable barcode readability across standard and specialized labeling requirements.

The Honeywell EL3-00-1JG05Q0L prints at 5 inches per second, making it efficient for moderate to high-volume labeling operations. This speed balances productivity with print quality, ideal for warehouses processing multiple shipments daily.

The Honeywell EL3-00-1JG05Q0L is classified as an industrial desktop printer, built to withstand continuous operation in demanding warehouse and logistics environments. Its robust construction, LCD interface, and reliable 300 DPI output make it suitable for mission-critical labeling applications.

We offer the Honeywell EL3-00-1JG05Q0L barcode label printer as part of our comprehensive AIDC equipment selection. Contact us today or visit barcodesinc.com to check availability, pricing, and to discuss which printer model best fits your warehouse labeling requirements.
