2.4 m (8 ft) to concrete per MILSTD 810G; 1.8 m (6 ft) to concrete across operating temperature range per MIL-STD 810G; 2,000 (1 m) tumbles per IEC 60068-2-32 specification
Processor & Chipset
Processor Type:
OMAP
Processor Speed:
1 GHz
Memory
Standard Memory:
512 MB
Flash Memory:
1 GB
Memory Card Supported:
microSD
Display & Graphics
Screen Size:
3.5"
Screen Mode:
VGA
Screen Resolution:
640 x 480
Display Screen Type:
LED
Touchscreen Information
Touchscreen:
Yes
Keyboard/Keypad
Keyboard Layout:
QWERTY
Keyboard Type:
Numeric
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n
Bluetooth:
Yes
Bluetooth Standard:
Bluetooth 2.1 + EDR
Cellular Network Supported:
CDMA
GSM
GPS:
Yes
Interfaces/Ports
USB:
Yes
Serial:
Yes
Camera
Rear Camera:
Yes
Rear Camera Resolution:
5 Megapixel
Software
Operating System:
Microsoft Windows Embedded Handheld 6.5
Power Description
Power Source:
Battery
Battery Information
Battery Capacity:
4000 mAh
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Battery Voltage:
3.70 V
Removable Battery:
Yes
Physical Characteristics
Rugged:
Yes
Width:
3.1"
Depth:
1.3"
Weight (Approximate):
15.87 oz
Miscellaneous
Application/Usage:
Field Sales/Service
Transportation
Ingress Protection (IP) Rating:
IP67
Environmentally Friendly:
Yes
Environmental Compliance:
Waste Electrical and Electronic Equipment Directive (WEEE)
What operating systems does the Honeywell CN70 mobile computer support?
The Honeywell CN70 supports both Windows Embedded Handheld 6.5 and Android 6.0 Marshmallow with GMS, giving you flexibility to choose the operating system that best fits your existing applications and business needs. This dual-OS capability allows organizations to transition smoothly between platforms without replacing hardware.
Is the Honeywell CN70 rugged enough for warehouse and field environments?
Yes, the CN70 is built for demanding environments with an IP67 rating for dust and moisture protection, and it can withstand 2.4 m (8 ft) drops to concrete per MIL-STD 810G specifications. The device also survives 2,000 tumbles from 1 m, making it ideal for warehouse, logistics, and field service applications where durability is critical.
What are the scanning capabilities of the CN70 mobile computer?
The CN70 features an advanced barcode imager with motion tolerance and white illumination with laser aiming, enabling fast and accurate scanning even in low-light conditions. The high-performance imaging technology delivers optimal read rates across a wide range of barcode types and scanning distances, making it ideal for scan-intensive warehouse and logistics operations.
How long does the battery last on a single charge?
The CN70 is equipped with a 3.7 V, 4000 mAh Li-Ion rechargeable battery that provides exceptional battery life to support extended work shifts without downtime. The smart battery technology ensures reliable operation throughout the full workday, though actual runtime depends on usage patterns and wireless connectivity.
What connectivity options are available on the CN70?
The CN70 offers extensive connectivity with Wi-Fi (802.11a/b/g/n), Bluetooth, and flexible WWAN radio options that support multiple networks worldwide for seamless communication. These advanced wireless capabilities enable real-time data synchronization and communication in warehouse, field service, and logistics environments.
What are the memory and storage specifications for the CN70?
The CN70 features 2 GB of RAM and 16 GB of internal Flash storage, with a customer-accessible micro-SD slot that supports removable memory cards up to 32 GB for expanded storage capacity. This configuration provides ample memory for enterprise applications and data collection in the field.
