The Honeywell 8680i Wearable Mini Mobile Computer is a compact, high-performance device that revolutionizes workflow efficiency in demanding environments. By combining the functionality of a scanner and mobile computer into a single ergonomic device, the 8680i enhances productivity through hands-free operation. Its customizable user interface and advanced connectivity options allow for streamlined workflows tailored to various applications, from picking to packing. Built to withstand rugged conditions, the 8680i ensures reliability and performance, making it an ideal solution for businesses seeking to elevate their operational effectiveness.
Key Features
Ergonomic Wearable Design: Enhances efficiency in frequent scanning tasks.
Cost-Effective Solution: Combines scanner and mobile computing functionalities, reducing acquisition costs.
Customizable Accessories: Options for ring or glove form factors and various battery sizes.
Rugged Durability: Designed to endure tough operating environments with specifications for drops and tumbles.
Honeywell Connected Workflow: Offers analytics for battery lifecycle management and simple deployment for updates.
Specifications
Mechanical:
Dimensions: Slim Battery - 81 mm x 56 mm x 31.3 mm; Extended Battery - 81 mm x 56 mm x 35 mm
Weight: Triggered Ring with Slim Battery - 151 g; Triggered Ring with Extended Battery - 168 g
Scan Performance:
Scan Pattern: Omni-directional area imager
Motion Tolerance: Up to 584 cm/second
Typical Range: Varies by symbology from 44 mm to 812 mm
Environmental:
Operating Temperature: -20°C to 50°C
Drop and Tumble Ratings: 30 drops from 1.5 m; 2,000 tumbles from 0.5 m
Warranty: Two-year factory warranty (one year for battery)
Honeywell 8680IB401-2-N Mobile Computer Overview
The 8680i is a compact, high-performance, hands-free mini mobile computer to help businesses improve workflow efficiency.
The 8680i Advanced model drives streamlined workflows onto a single device for many applications, replacing a scanner and mobile computer. The customizable user-facing display communicates workflow instructions, while the two-button interface enables users to navigate menus and confirm selections. The 8680i wearable mini mobile connects directly to the network application through WiFi and the SDK. Converging common applications such as picking, packing, and sorting onto a single device offers improved ergonomics and reduced acquisition cost when replacing current wearable scanner plus mobile computer solutions.
A Standard version offers lightweight, ergonomic Bluetooth®-wearable scanning with clear communication of wireless connection, battery status, and scan results when paired with another device.
Configuration options help tailor the 8680i device to the environment. It is available (and field-reconfigurable) with two-finger ring or back-of-hand glovemount options, and can use slim or extended batteries to suit the duty cycle, shift length, and size/weight priorities. With performance to drive effective workflows and durability to survive tough operating environments, the 8680i wearable mini mobile can add efficiency and effectiveness to the most common tasks.
FEATURES AND BENEFITS
The 8680i wearable mini mobile is designed to speed frequent scanning tasks, leaving hands free to do the job needed.
Advanced version offers customizable line-of-sight screen, Wi-Fi, and SDK for application development, enabling the 8680i device to support streamlined workflows as a standalone device, replacing scanner + mobile computer alternatives.
Field-reconfigurable accessories to the device module enable ring or glove form factor; extended or slim batteries tailor size/ weight to duty cycle needs; Standard or Advanced versions to fit workflow needs.
Engineered for 2,000 0.5 meter (1.6 feet) tumbles, the 8680i wearable mini mobile is built to endure rugged work environments.
Honeywell Operational Intelligence workflow analytics to manage battery population lifecycle, ensuring uninterrupted full-shift operation; simple deployment of setting and firmware updates.
Two-finger ring strap for triggered configuration (package of 10). Triggered ring strap mount (Part# 8680i505RINGMT) required to attach to 8680i device must be ordered separately.
Triggered ring-strap mount (package of 10, includes trigger component). Two-finger ring strap for triggered configuration (Part# 8680i505FNGRSTRAP ) must be ordered separately.
8680i Right hand strap glove with device harness, one size, package of 10, trigger on index finger. Glove mount (8680i505GMT) required to attach to 8680i device must be ordered separately.
4 Bay 8680i Battery Charger. Charges battery only when removed from 8680i. Compatible with Extended or Slim batteries. Region-specific cord, US line cord is(Part# 19-19726) must be ordered separately.
4 Bay 8680i Device Charger. Charges complete 8680i unit with extended or slim battery installed. Region-specific cord, US line cord is (Part# 19-19726) must be ordered separately.
12 Bay 8680i Battery Charger. Charges battery only when removed from 8680i. Compatible with Extended or Slim batteries. Region-specific cord must be ordered separately.
What are the key features of the Honeywell 8680i wearable mobile computer?
The Honeywell 8680i is a compact, high-performance wearable mini mobile computer that combines scanner and mobile computing functionality into a single ergonomic device. It features an omni-directional area imager for 1D/2D barcode scanning, customizable user-facing display for workflow instructions, WiFi connectivity, and hands-free operation with a two-button interface. The device is available in standard and advanced models, with the advanced version integrating picking, packing, and sorting applications onto a single device. We offer the 8680i with triggered ring and hook-and-loop strap attachments to accommodate various work environments.
What are the durability and environmental specifications for the 8680i?
The Honeywell 8680i is built for rugged environments with a two-year factory warranty and can withstand 30 drops from 1.5 meters (4.9 feet) to concrete and 2,000 tumbles. It operates reliably in temperatures from -20°C to 50°C (-4°F to 122°F) and maintains functionality in humidity levels up to 95% relative humidity non-condensing. The device's ergonomic wearable design ensures durability during frequent scanning tasks in demanding warehouse, manufacturing, and logistics operations.
What scanning performance can I expect from the 8680i?
The 8680i features an omni-directional area imager with excellent scanning range across multiple barcode types. For example, it reads 10 mil Code 39 barcodes from 65 mm to 544 mm (2.6 to 21.4 inches), 20 mil Code 39 from 49 mm to 812 mm (1.9 to 32 inches), and 100% UPC codes from 44 mm to 552 mm (1.7 to 21.7 inches). The device supports motion tolerance up to 584 cm (230 inches) per second with flexible pitch (±45°) and skew (±60°) tolerance, making it ideal for fast-paced scanning operations.
Is the Honeywell 8680i compatible with existing warehouse management systems?
Yes, the 8680i connects directly to network applications through WiFi and includes an SDK for custom integration with your existing systems. The device also supports offline functionality through TotalFreedom plugin development, allowing you to maintain operations even when network connectivity is temporarily unavailable. Contact us today to discuss integration requirements with your specific warehouse management or enterprise resource planning systems.
What battery options are available for the 8680i, and how long does it operate?
The Honeywell 8680i is available in two battery configurations: a slim battery version (81 mm x 56 mm x 31.3 mm, 151 g with triggered ring) and an extended battery version (81 mm x 56 mm x 35 mm, 168 g with triggered ring). Both versions use a 3.6V, 3400 mAh battery providing a minimum of 6 hours of operation, with a 3-hour charge time using a battery charger or 3.5 hours with the device charger. Note that batteries and chargers are sold separately and required for use—visit barcodesinc.com to select the appropriate charging solution for your deployment.
What industries and applications is the 8680i designed for?
The Honeywell 8680i is purpose-built for warehouse, manufacturing, retail, hospitality, transportation, and logistics environments where hands-free, wearable scanning improves workflow efficiency. The device excels in picking, packing, and sorting operations where workers need to maintain mobility and use both hands while scanning. Its customizable interface and rugged design make it ideal for businesses seeking to combine scanner and mobile computing functionality into a single cost-effective solution. Contact us today to discuss how the 8680i can optimize your specific operational workflows.
The Honeywell 8680IB401-2-N Mobile Computer is also known as
HSM-8680IB4012N
or 8680IB4012N.
Full specifications (PDF)
