Honeywell 8680i – Mobile Computer
Full specifications (PDF)
Honeywell 8680i Mobile Computer Model Overview
The Honeywell 8680i Wearable Mini Mobile Computer is a compact, high-performance device that revolutionizes workflow efficiency in demanding environments. By combining the functionality of a scanner and mobile computer into a single ergonomic device, the 8680i enhances productivity through hands-free operation. Its customizable user interface and advanced connectivity options allow for streamlined workflows tailored to various applications, from picking to packing. Built to withstand rugged conditions, the 8680i ensures reliability and performance, making it an ideal solution for businesses seeking to elevate their operational effectiveness.
Key Features
- Ergonomic Wearable Design: Enhances efficiency in frequent scanning tasks.
- Cost-Effective Solution: Combines scanner and mobile computing functionalities, reducing acquisition costs.
- Customizable Accessories: Options for ring or glove form factors and various battery sizes.
- Rugged Durability: Designed to endure tough operating environments with specifications for drops and tumbles.
- Honeywell Connected Workflow: Offers analytics for battery lifecycle management and simple deployment for updates.
Specifications
- Mechanical:
- Dimensions: Slim Battery - 81 mm x 56 mm x 31.3 mm; Extended Battery - 81 mm x 56 mm x 35 mm
- Weight: Triggered Ring with Slim Battery - 151 g; Triggered Ring with Extended Battery - 168 g
- Scan Performance:
- Scan Pattern: Omni-directional area imager
- Motion Tolerance: Up to 584 cm/second
- Typical Range: Varies by symbology from 44 mm to 812 mm
- Environmental:
- Operating Temperature: -20°C to 50°C
- Drop and Tumble Ratings: 30 drops from 1.5 m; 2,000 tumbles from 0.5 m
- Wireless:
- Bluetooth v 4.1 and Wi-Fi 802.11 a/b/g/n/ac
- Battery: Slim (3.6 V, 1200 mAh), Extended (2160 mAh)
- Warranty: Two-year factory warranty (one year for battery)
Recommended Accessories
Category
- Batteries (3)
- Cables, Connectors, and Adapters (1)
- Carrying and Protective Accessories (6)
- Docks and Cradles (4)
- General Software (1)
- Mobile Computer Accessories (2)
- Mounting Hardware and Stands (2)
- Scanner Accessories (10)
- Spare Parts (4)
Recommended Accessories for Model: Honeywell 8680I400-2 Mobile Computer
Top Batteries Purchased With Honeywell 8680I400-2
-
Honeywell BAT-SCN03 BatterySlim Battery. Provides 3,000 scans in 8 hours under normal conditionsItem on backorder — chat for lead time$105.34 -
Honeywell BAT-SCN02 BatteryExtended Battery. Provides 8,000 scans in 10 hours under normal conditionsItem on backorder — chat for lead time$145.03 -
Honeywell BAT-SCN02A BatteryBattery, Wearable Mini Mobile Extended Battery, Compatible with 8680iIn Stock$137.77
Top Cables, Connectors, and Adapters Purchased With Honeywell 8680I400-2
-
Honeywell 19-19726 Cables, Connectors, and AdaptersPower cable û U.S.Item on backorder — chat for lead time$22.43
Top Carrying and Protective Accessories Purchased With Honeywell 8680I400-2
-
Honeywell 8680i505FNGRSTRAP Carrying and Protective AccessoriesTwo-finger ring strap for triggered configuration (package of 10). Triggered ring strap mount (Part# 8680i505RINGMT) required to attach to 8680i device must be ordered separately.Item on backorder — chat for lead time$106.23 -
Honeywell 8680i505RINGMT Carrying and Protective AccessoriesTriggered ring-strap mount (package of 10, includes trigger component). Two-finger ring strap for triggered configuration (Part# 8680i505FNGRSTRAP ) must be ordered separately.Item on backorder — chat for lead time$1,176.06 -
Honeywell 8680i505RHSGH Carrying and Protective Accessories8680i Right hand strap glove with device harness, one size, package of 10, trigger on index finger. Glove mount (8680i505GMT) required to attach to 8680i device must be ordered separately.Item on backorder — chat for lead time$973.46
Top Docks and Cradles Purchased With Honeywell 8680I400-2
-
Honeywell MB4-BAT-SCN02 Accessory4 Bay 8680i Battery Charger. Charges battery only when removed from 8680i. Compatible with Extended or Slim batteries. Region-specific cord, US line cord is(Part# 19-19726) must be ordered separately.In Stock$487.48 -
Honeywell MB4-SCN02 Accessory4 Bay 8680i Device Charger. Charges complete 8680i unit with extended or slim battery installed. Region-specific cord, US line cord is (Part# 19-19726) must be ordered separately.Item on backorder — chat for lead time$473.66 -
Honeywell MB12-BAT-SCN02 Accessory12 Bay 8680i Battery Charger. Charges battery only when removed from 8680i. Compatible with Extended or Slim batteries. Region-specific cord must be ordered separately.Item on backorder — chat for lead time$1,381.23
Top General Software Purchased With Honeywell 8680I400-2
-
Honeywell SW-ADV-8680i SoftwareStandard-to-advanced software upgrade (US)Item on backorder — chat for lead time$269.58
Top Mobile Computer Accessories Purchased With Honeywell 8680I400-2
-
Honeywell 8690ITRGRNSTRP10 Spare Parts8680i/8690i Reversible trigger, pivot, and hook and loop strap assembly for triggered ring configurations (package of 10)In Stock$687.77 -
Honeywell 8690ITRGR10 Spare Parts8680i/8690i Reversible trigger and pivot assembly for triggered ring configurations (package of 10)Item on backorder — chat for lead time$499.36
Top Mounting Hardware and Stands Purchased With Honeywell 8680I400-2
-
Honeywell 8680i505GMT Accessory8680i Glove mount (package of 10). 8680i, gloves purchased separatelyIn Stock$883.85 -
KENWOOD J19-5577-03 AccessoryAccessory Locking Bracket for TK-240x, TK-340x, IS, NX-240x, NX-340x radioItem on backorder — chat for lead time$6.52
Top Scanner Accessories Purchased With Honeywell 8680I400-2
-
Honeywell AP-010BT-07N AccessoryXenon Access Point (Class 1, Bluetooth, RS232/USB/KBW/IBM)Item on backorder — chat for lead time$427.14 -
Honeywell AP-100BT-07N AccessoryACCESS POINT CLASS 1 BLTH 100M (300FT) UP TO 7 SCANNERS RS232/USB/KBW (REQ CBL). Non-Cancelable/Non-Returnable.Item on backorder — chat for lead time$386.12 -
Honeywell AP05-100BT-07N AccessoryACCESS POINT FOR GRANIT 1981I, CLASS 1 BLUETOOTH, 100M (300FT), UP TO 7 SCANNERS CAN BE CONNECTED, RS232/USB/KBWItem on backorder — chat for lead time$438.46
Top Spare Parts Purchased With Honeywell 8680I400-2
-
Honeywell 8690ITRGRNSTRP10 Spare Parts8680i/8690i Reversible trigger, pivot, and hook and loop strap assembly for triggered ring configurations (package of 10)In Stock$687.77
-
Honeywell 8690ITRGR10 Spare Parts8680i/8690i Reversible trigger and pivot assembly for triggered ring configurations (package of 10)Item on backorder — chat for lead time$499.36
-
Honeywell 8690I505CPAD10 Spare PartsSpare Part, Honeywell, 8690I/8680I Triggered Ring Comfort Pad, Pack Of 10Item on backorder — chat for lead time$56.47
Frequently Asked Questions
What is the Honeywell 8680i and what problems does it solve?
The Honeywell 8680i is a compact, high-performance wearable mini mobile computer that combines the functionality of a barcode scanner and mobile computer into a single ergonomic device. It eliminates the need to carry separate scanning and computing tools, reducing costs and improving workflow efficiency for picking, packing, sorting, and other hands-free operations in warehouse and logistics environments.
What are the scanning capabilities and performance specifications of the 8680i?
The 8680i features an omni-directional area imager with 1D/2D barcode scanning capabilities, supporting symbologies including Code 39, DataMatrix, PDF417, and UPC. It delivers typical scanning ranges from 44 mm to 812 mm depending on barcode type, with motion tolerance up to 584 cm/second and pitch/skew tolerance of ±45°/±60°, making it suitable for fast-paced warehouse operations.
How durable is the Honeywell 8680i in harsh warehouse environments?
The 8680i is engineered for rugged durability with a design that withstands 30 drops from 1.5 meters (4.9 feet) to concrete and 2,000 tumble cycles. It operates reliably in temperatures from -20°C to 50°C (-4°F to 122°F) and humidity levels up to 95% non-condensing, making it ideal for demanding warehouse, manufacturing, and logistics applications.
What connectivity and integration options does the 8680i offer?
The 8680i connects to network applications through WiFi and includes an SDK for custom development and offline functionality through TotalFreedom plugin development. Its Bluetooth wireless connection enables pairing with other devices, and the customizable user-facing display communicates workflow instructions directly to operators, streamlining operations across picking, packing, and sorting workflows.
What battery options are available for the 8680i?
The 8680i is available in two battery configurations: a slim battery version (81 mm x 56 mm x 31.3 mm, 151 g with triggered ring) and an extended battery version (81 mm x 56 mm x 35 mm, 168 g with triggered ring). Both versions use a 3.6V, 3400 mAh battery providing minimum 6 hours of operation, with a 3-hour charge time. Note that battery and charger are sold separately and required for use.
What form factors and accessories are available for the 8680i?
The 8680i offers customizable wearable form factors including triggered ring and hook-and-loop strap attachments, allowing users to wear the device in ring or glove configurations based on their workflow needs. These ergonomic accessories enhance efficiency during frequent scanning tasks while maintaining hands-free operation in fast-paced warehouse and logistics environments. Contact us today to explore configuration options available from us.
