The Datalogic Matrix 320 features a superior 2MP image-based sensor with LED array lighting that delivers exceptional performance for traceability applications. This advanced imaging technology competes against 3MP readers while offering an extra-large field of view, making it ideal for both end users and machine builders seeking the best price-to-performance ratio.

The Matrix 320 reads a comprehensive range of 1D codes including Code 128, Code 39, EAN/UPC, and GS1 DataBar, as well as 2D codes such as DataMatrix, QR Code, Aztec, and Maxicode. It also supports postal codes like Royal Mail and Japan Post, making it versatile for diverse traceability and identification needs across industrial environments.

The Matrix 320 offers multiple connectivity modes including RS232, optocoupled RS422/RS485 up to 115.2 Kbit/s, and Ethernet (10 Base T and 100 BaseTx). It supports Pass Through, Master/Slave, Multiplexer, and network configurations, giving you flexibility to integrate it into your existing warehouse or manufacturing systems. Contact us today to discuss the right connectivity solution for your application.

Yes, the Matrix 320 is specifically designed as a stationary, fixed-mount industrial scanner for demanding traceability applications. Its robust construction, programmable digital inputs and outputs, and advanced optical performance make it ideal for high-speed production lines and automated material handling environments. We offer the Matrix 320 with multiple SKU variants to match your specific mounting and configuration requirements.

The Matrix 320 uses Windows-based VisiSet™ software for programming and configuration via serial or Ethernet connection. The scanner includes diagnostic tools for exposure indication, code position and orientation analysis, and decoding time measurement, allowing your IT team to optimize performance for your specific application. Visit barcodesinc.com for technical documentation and setup support.

The Matrix 320 supports a maximum pitch of ±35° and full 360° tilt capability, with direct or 90° reading window options available. This flexible orientation support ensures reliable barcode capture even in challenging mounting positions or when codes are presented at various angles on your production line.
