Honeywell 6920-3 Credit Card Swiper
Honeywell 6920-3 Credit Card Swiper
Honeywell ScanTeam 6920 -
Keyboard wedge interface, reads tracks 1 & 2. Includes PS/2 cable.
Full specifications (PDF)The ScanTeam 6920 offers a fast, easy, and accurate method of entering data contained on a magnetic stripe into a PC system.
ScanTeam 6920 products are Magnetic Stripe Card Readers (MSRs) which attach to PCs through a Keyboard wedge interface. The magnetic stripe data transmitted by the ScanTeam 6920 to the PC emulates keyboard data input. For many applications, no PC program modification is required to input data from the ScanTeam 6920. The ScanTeam 6920 is a bi-directional card reader, it can read cards swiped in either direction. A beeper and LED indicate a good read or bad read.
Honeywell 6920-3 Overview
The SCANTEAM 6920-3 Magnetic Stripe Card Reader (MSR) attaches to PC through a keyboard wedge interface. The magnetic stripe data transmitted by the ST6920-3 emulates keyboard data input. The ST6920-3 draws all power from its keyboard interface cables, and thus does not require an external power pack.
Technical Information
Magnetic Stripe Track Configuration:
Dual Track
Magnetic Stripe Track Number:
- Track 1
- Track 2
Magnetic Head Life:
300 Swipe
Interfaces/Ports
Keyboard Wedge:
Yes
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Height:
1.7"
Width:
3.9"
Depth:
1.3"
Weight (Approximate):
10.60 oz
Miscellaneous
Certifications & Standards:
FCC Class A EMC 89/336/EEC
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC:
43211702
The Honeywell 6920-3 is also known as HHP-6920-3 or 69203 .
