Honeywell 4820ISR-SERKITAE Barcode Scanner

A newer version of this item is available.
It is replaced by the Honeywell 1911IER-3 Barcode Scanner.

Honeywell 4820i - RS-232 kit, Standard Range. Includes scanner, cradle, RS-232 cable, power supply, and user guide.

Creates a high ROI because of diminishment in workforce and descend inventory errors
Incredible and responsive 2D scanning even on curved or translucent surfaces
Regardless of angle orientation, the imager makes it easy to scan 1D and 2D barcodes
Laser-free design provides high-performance scanning without the risk of eye injury
Increase productivity and performance by excluding the cable
With Bluetooth technology, you can scan barcodes and then transmit data from the base

Need a different version? See all Honeywell 4820i Barcode Scanners

Discontinued See Replacement

Add to Quote

Honeywell 4820ISR-SERKITAE Barcode Scanner

Overview

Full specifications (PDF)

Honeywell 4820i Barcode Scanner Model Overview

4820i 2D imager from Honeywell offers an ideal solution for industrial mobile barcode reading applications. It features a sturdy "Industrial Ruggedness" construction, Bluetooth v1.2 radio wireless communications for freedom of movement in retail, warehouse and distribution. This enables movement up to 33 feet (10m) from the base while its Adaptive Frequency Hopping (AFH) feature eliminates interference with other wireless systems. The field-replaceable lithium-ion battery enables up to 57,000 reads per full charge. The 4820i's small footprint enables hands-free presentation scanning when docked in the base. The host-powered interface and RF link extends the mobile capabilities of the 4820i by drawing power from a portable device for radio and host communications.

Honeywell 4820ISR-SERKITAE Barcode Scanner Overview

The 4820i Standard Range

Detailed Specs

Full specifications (PDF)

Technical Information

Connectivity Technology:

Wireless

Scanning Capability:

Barcode Symbology Supported:

PDF 417
Micro PDF-417
MaxiCode
DataMatrix
QR Code
Aztec
Aztec Mesas
Code 49
EAN-UCC Composite
Codabar
Code 39
Interleaved 2 of 5
Code 93
Code 128
UPC
EAN
Postnet
Planet Code
British Post
Canadian Post
Japanese Post
KIX(Netherlands) Post
OCR-A
OCR-B

Light Source:

LED

Image Sensor Type:

Imager

Maximum Scan Resolution:

6.60 mil

Depth of Field:

0.008"@8.3mil - Linear
0.012"@13mil - UPC
0.0060"@6.6mil - PDF417
0.0090"@10mil - PDF417
0.014"@15mil - Data Matrix
0.035"@35mil - Maxi Code

Scan Pattern:

Omni-directional

Cable Type Included:

Serial

Network & Communication

Bluetooth:

Yes

Interfaces/Ports

Host Interface:

Multi-interface

Power Description

Power Supply Included:

Yes

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Physical Characteristics

Color:

Orange

Height:

6.5"

Width:

3.2"

Depth:

5.3"

Weight (Approximate):

9.59 oz

Miscellaneous

Package Contents:

4820i Bar Code Reader
Base
Power Supply
RS-232 Cable
User Documentation
Power Cord

Additional Information:

USB Cable separate

Certifications & Standards:

FCC Class B
CE EMC Class B
CE Low Voltage Directive
IEC60825-1 LED Safety: Class 1
UL
cUL listed
TÜV
2005 Sunrise Compliant

Warranty

Limited Warranty:

5 Year

Item Numbers

UNSPSC: 43211701

Reviews

Q&A

Accessories

Service Contracts

Get help from a Barcoding Expert!

The Honeywell 4820ISR-SERKITAE Barcode Scanner is also known as HHP-4820ISR-SERKITAE or 4820ISRSERKITAE.
