Honeywell 4800ISF051C-0F00E Barcode Scanners

The 4800i Industrial 2D Area Imager, powered by Adaptus Imaging Technology 5.0, decodes faster, farther, and future-proofs your investment. The 4800i helps employees spend less time trying to capture data, and more time creating a productive and cost effective work environment.

Technical Information

Barcode Dimension:
- 1D
- 2D
Connectivity Technology: Cable
Light Source: LED
Image Sensor: Imager
Barcode Symbology Supported:
- PDF 417
- Micro PDF-417
- MaxiCode
- DataMatrix
- QR Code
- Aztec
- Aztec Mesas
- Code 49
- EAN-UCC Composite
- Codabar
- Code 39 including PARAF
- Interleaved 2 of 5
- Code 2 of 5
- Code 11
- Code 93
- Code 128
- UPC
- EAN/JAN
- RSS
- Postnet
- Planet Code
- British Post
- China Postal Code
- Canadian Post
- Japanese Post
- KIX(Netherlands) Post
- OCR-A
- OCR-B
- PDF 417
- Micro PDF-417
- MaxiCode
- DataMatrix
- QR Code
- Aztec
- Aztec Mesas
- Code 49
- EAN-UCC Composite
- Codabar
- Code 39 including PARAF
- Interleaved 2 of 5
- Code 2 of 5
- Code 11
- Code 93
- Code 128
- UPC
- EAN/JAN
- RSS
- Postnet
- Planet Code
- British Post
- China Postal Code
- Canadian Post
- Japanese Post
- KIX(Netherlands) Post
- OCR-A
- OCR-B
Maximum Scan Resolution: 15 mil
Depth of Field:
- 2" - 6"@7.50 mil - Linear
- 1.50" - 8.40"@13 mil - UPC
- 2.30" - 5.50"@6.60 mil - PDF417
- 1.70" - 7.10"@10 mil - PDF417
- 1.30" - 7"@15 mil - Data Matrix
- 1.70" - 6.70"@15 mil - QR Code

General Information

Product Type: Handheld Barcode Scanner
Brand Name: Honeywell
Manufacturer: Honeywell International, Inc
Product Model: 4800i
Product Name: 4800i Barcode Reader

Physical Characteristics

Height: 6.4"
Width: 3.2"
Depth: 5.3"
Color: Orange
Weight (Approximate): 7.50 oz

Interfaces/Ports

Host Interface: Multi-interface

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS
Package Contents:
- 4800i Barcode Reader
- USB Straight Cable
- User Documentation
- 4800i Barcode Reader
- USB Straight Cable
- User Documentation
Certifications & Standards:
- FCC Class B
- CE EMC Class B
- CE Low Voltage Directive
- IEC60825-1 LED Safety: Class 1
- UL
- cUL
- TÜV
- 2005 Sunrise
- RoHS
Additional Information:
- Supported Interfaces:
- Serial
- USB
- Keyboard Wedge
- IBM 4683
- Wand Emulation

Warranty

Limited Warranty: 5 Year

Power Description

Input Voltage: 5 V DC

Full specifications (PDF)

See all Honeywell 4800i options »

Brand	Honeywell
Model	4800i
Form Factor	Handheld
Connectivity	Corded
Scanner Type	Imager
Color	Orange
Included Cables	USB
Ruggedness	Rugged
