Honeywell 4600g – Barcode Scanner – 1D

Part Number: 4600GSR051C-0A00E
Model: 4600g
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Interface Options
PS/2 Keyboard Wedge
Scanner Capability
1D

Product Description:

  Keyboard Wedge kit with PS/2 cable, Standard Range Area Imager and user guide. Color: Gray. RoHS Compliant.
Explore all Honeywell 4600g Barcode Scanners
Add to Quote
Honeywell 4600GSR051C-0A00E Barcode Scanner
Honeywell 4600GSR051C-0A00E Barcode Scanner
Honeywell 4600GSR051C-0A00E Barcode Scanner
Honeywell 4600GSR051C-0A00E Barcode Scanner
Honeywell 4600GSR051C-0A00E Barcode Scanner Honeywell 4600GSR051C-0A00E Barcode Scanner Honeywell 4600GSR051C-0A00E Barcode Scanner Honeywell 4600GSR051C-0A00E Barcode Scanner
Full specifications (PDF)

Honeywell 4600g Barcode Scanner Model Overview

The 4600g area imager from Honeywell combines the versatility of area imaging with the speed and cost of linear scanning for demanding retail and commercial applications. Powered by Adaptus imaging, the 4600g is full featured, fast, and cost effective. Durable, with no moving parts to wear out and Honeywell backs this with a best-in-class 3 year warranty.
Honeywell 4600GSR051C-0A00E Barcode Scanner Overview

The 4600gSR Bar Code Reader combines the right blend of performance and durability for a wide variety of applications that benefit from the power and versatility of a 2D imaging solution.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:

2 Dimensional:

  • PDF417
  • MicroPDF417
  • MaxiCode
  • Data Matrix
  • QR Code
  • Aztec
  • Aztec Mesas
  • Code 49
  • EAN UCC Composite

Linear:

  • Code 39
  • Code 128
  • Codabar
  • UPC
  • EAN
  • RSS
  • Code 93
  • Codablock F

Postal :

  • Posnet (US)
  • Planet Code
  • BPO State
  • Canadian State
  • Japanese Post
  • KIX (Netherlands) Post

OCR Fonts:

  • OCR-A
  • OCR-B
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
35 mil
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
Handheld
Product Color:
Gray
Height:
6.2"
Width:
3.2"
Depth:
5.3"
Weight (Approximate):
6.50 oz
Miscellaneous
Package Contents:
  • 4600gSR Bar Code Reader
  • Coiled Keyboard Wedge Cable
  • User Documentation
Additional Information:

Supported Interfaces:

  • All popular PCs and terminals via keyboard wedge
  • keyboard replacement/direct connect
  • USB
  • TTL level RS-232
  • Wand Emulation (primary interface only) mode
  • TTL level Serial Wedge
  • IBM 46XX retail terminals.

USB Cable separate

Platform Supported:
PC
Certifications & Standards:

RoHS

International:

  • CB scheme to IEC60950-1
  • CB scheme to IEC60825-1 Class 1 LED

USA:

  • FCC Part 15 subpart B Class A. UL listed to 60950-1.

Canada:

  • ICES-003 Class A. cUL listed to CSA C22.2 No. 60950-1-03.

Europe:

  • CE 2004/108/EC EMC Directive to EN55022 Class A
  • EN55024
  • EN61000-3-2
  • EN61000-3-3. 2006/95/EC Low Voltage Directive.

GS Mark:

  • I.T.E. safety.

Australia/NZ:

  • C-Tick mark.

Laser Classification:

  • Laser Aimer Model only: Class 2 Laser IEC60825-1. Complies with 21 CFR 1040.10 and 1040.11 with Laser Notice No. 50. 1mW max output, 650 nM
Warranty
Limited Warranty:
5 Year
Item Numbers
