Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
Linear:
- BC412 (requires end-user license from IBM)
- China Post
- Codabar (NW7)
- Code 11
- Code 128
- Code 2 of 5
- Code 32
- Code 39
- Code 93 and 93i
- EAN
- GS1 DataBar (formerly RSS)
- Interleaved 2 of 5
- Label Code
- Matrix 2 of 5
- MSI
- Plessey
- PosiCode
- Telepen
- Trioptic Code
- UPC
Stacked:
- Codablock F
- Code 16K
- Code 49
- GS1 Composite (formerly EAN/UCC)
- MicroPDF417
- PDF417
- TCIF Linked Code 39 (TLC39)
Matrix:
- Aztec
- Chinese Sensible Code (Han Xin Code)
- Data Matrix
- Grid Matrix Code
- MaxiCode
- Micro QR Code
- QR Code
Postal:
- Australian Post
- British Post
- Canadian Post
- ID-tag (UPU 4-state)
- Intelligent Mail Barcode (formerly 4-state customer barcode)
- Japanese Post
- Korea Post
- Netherlands (KIX) Post
- Planet Code
- Postnet
OCR:
- OCR-A
- OCR MICR (E 13 B)
- OCR-B
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
5 mil
Depth of Field:
- 1.9" - 3.8"@5mil
- 1.6" - 6.2"@13mil - UPC
- 1.6" - 4.5"@6.6mil - PDF
- 2.4" - 3.5"@6.7mil - DM
- 2.3" - 3.4"@6.7mil - QR
Scan Pattern:
Omni-directional
